S CLASS™ cutter User’s Manual
Setup 1-45
1.6.2.2 Pen installation
The S CLASS™ tangential cutters can also be operated with a ballpoint pen. After replacing
the knife with a pen, the cutter can be used as a plotter to draw draft plots of new or
existing designs on paper.
1. Turn the installed tool counterclockwise. The holder will raise up, making it possible to
lift the knife holder out of the tangential head. Underneath is the place for a nosepiece.
Remove this part also if it is mounted.
2. Insert the ballpoint pen holder into the tool shaft.
3. Gently insert the ballpoint pen into the tool shaft. Turn the ballpoint pen clockwise all
the way down.
4. The change of tool can either be input on the touch screen with Summa Cutter Control,
or with the cutting software.
Selecting pen operation changes the pressure to “pen pressure.”
NOTE: The information on the touch panel shows the tool currently selected by the cutter.
Make sure the cutter’s tool setting matches the actual tool in use.
1.6.2.3 Pouncing pin installation
The S CLASS™ tangential cutters can also be operated with a pouncing tool. After replacing
the knife with a pouncing tool, the cutter can be used as a pouncer.
1. Turn the installed tool counterclockwise. The holder will rise up, making it possible to
lift the tool out of the tangential head. Underneath is the place for a nosepiece. Remove
this part also if it is mounted.
2. Remove the black plug from the front tool shaft.
3. Gently insert the pouncer into the front tool shaft. Turn the pouncer clockwise all the
way down.
4. The change of tool can either be input on the touch screen with Summa Cutter Control,
or with the cutting software.
Selecting pouncer operation changes the pressure to “pouncer pressure” and adds
“pouncing gap” to tool properties.
NOTE: The information on the touch panel shows the tool currently selected by the cutter.
Make sure the cutter’s tool setting matches the actual tool in use.
CAUTION: Before starting to pounce, check whether the pouncing tool is above the black
pouncing strip. If the pouncer is mounted in the rear slot of the clamp, the cutting strip will
be irreversibly damaged.
