S CLASS™ cutter User’s Manual
Setup 1-44
NOTE: The knife pressure can also be used to check the knife depth (which is controlled by
the amount the knife extends outs of the nosepiece). If the correct knife pressure is raised
by 150 gr, then the knife may not cut through the backing of the vinyl. If it does, then the
knife depth needs to be reduced.
CAUTION: After setting the cutting depth and/or the knife pressure, perform a thorough
visual check of the knife blade, which can be seen protruding from the knife holder, and
test cutting results on a scrap of vinyl media.
WARNING: Do not operate the cutter if the knife blade cuts through the media backing, as
this will seriously damage the cutter's rubber cutting strip and the knife.
CAUTION: For most vinyl cutting operations, the knife blade tip will be barely visible at the
bottom of the knife tool. If the knife blade tip is clearly visible, then the knife depth must be
readjusted.
To prevent damage to the cutter, check the depth of the knife blade tip and the quality of
the cut each time you load a different type of vinyl into the cutter.
