S CLASS™ cutter User’s Manual
Basic Operation 2-5
2.2 How to Set Tool Parameters
The S CLASS™ cutters can work with a knife, pen or pouncer. With the T version there is the
choice between drag knife and tangential knife.
Once a tool has been changed, then the tool parameters (menu settings) must be reset or
checked.
All the different tools have one parameter name in common: the pressure.
Each tool has also its specific parameters.
Tool parameters can be changed by either changing them in the current user, or simply by
changing user (see section 2.4).
NOTE: The S CLASS™ cutters will only perform according to specifications if a genuine
Summa knife, pen or pouncing tool is installed. Do not replace the standard knife, pen or
pouncing tool with products from other manufacturers.
Each keystroke can initiate an internal test or movement of head or media.
WARNING
KEEP FINGERS AND OTHER BODY PARTS AWAY FROM THE CUTTING AREA. THERE ARE
HAZARDOUS MOVING PARTS.
2.2.1 Setting tool type
1. Power on the cutter.
2. Press .
The main menu will appear on the screen.
3. Press .
The different configuration menus will appear on screen.
4. Press .
A list of possible tools will be shown.
5. Use or to change the tool.
6. Press to select the tool that is highlighted on screen.
