S CLASS™ cutter User’s Manual
Basic Operation 2-10
However, if the test cut resembles the pattern below, increase the value of the lateral
parameter to correct the closing lines cut.
Longitudinal correction
Weed (remove) out the rectangle and, if you obtained a pattern like the one below,
decrease the value of the longitudinal parameter to correct the closing lines cut.
However, if the test cut resembles the pattern below, increase the value of the
longitudinal parameter to correct the closing lines cut.
Each time a parameter is changed, press to perform the internal knife calibration
test.
NOTE: Failing to set the knife parameters correctly will result in poor cut quality.
