6-10 Sun Blade 150 Service Manual • June 2002
6.2.10 Replacing the Smart Card Reader Cable Assembly
1. Replace the smart card reader cable assembly as follows (FIGURE 6-6):
a. Position the smart card reader cable assembly into the chassis.
b. Close the cable routing clip.
c. Connect the smart card reader cable assembly connectors to the following:
■ Riser board (J8)
■ Smart card reader
Note – Ensure that the cable assembly connectors are properly oriented by aligning
the connector keys.
2. If you moved the fan assembly, replace it.
See “Replacing the Fan Assembly” on page 6-16.
3. Detach the wrist strap, replace the system cover, and power on the system as
described in Chapter 9.
6.2.11 Removing the Power Switch/LED Assembly
1. Power off the system, remove the system cover, and attach an antistatic wrist strap
as described in Chapter 5.
Caution – Use proper ESD grounding techniques when handling components. Wear
an antistatic wrist strap and use an antistatic mat. Store ESD-sensitive components in
antistatic bags before placing them on any surface.
2. Remove the front panel bezel by lifting the three tabs and gently lifting the bezel
from the system (
FIGURE 6-7).
