B-10 Sun Blade 150 Service Manual • June 2002
FIGURE B-8 Accessing the Second Serial Port Through a PCI Card Slot
Some third-party cables are too bulky to fit the Sun Blade 150 serial port and video
port. The Sun Blade 150 system was shipped with connector extensions to allow for
better connections with bulky third-party cables (
FIGURE B-9).
Internal serial port: Riser board J13
External serial port
