1-4 Sun Blade 150 Service Manual • June 2002
1.2 Supported Sun Monitors
The monitors listed in TABLE 1-1 can be used with the Sun Blade 150 system.
For more detailed information on these monitors contact your Sun representative or
see the following web site:
http://www.sun.com/products-n-solutions/hw/peripherals/
1.3 System Description
System components are housed in a desktop-style enclosure. Overall chassis
dimensions for the Sun Blade 150 system are listed in
TABLE 1-2.
System electronics are contained on a single plug-in printed circuit board
(motherboard). The motherboard contains the CPU, memory modules, system
control application-specific integrated circuits (ASIC), and I/O ASICs. The
motherboard plugs into a riser board that provides the system power and integrated
drive electronics (IDE) hard drive data interface.
FIGURE 1-2 and FIGURE 1-3 show the
Sun Blade 150 system front and back panels.
TABLE 1-1 Supported Sun Monitors
I/O Device Description
17-inch color CRT monitor Supports resolutions up to 1152x900
18.1-inch TFT LCD color monitor 1280x1024 resolution
21-inch CRT color monitor, flat
display
Supports resolutions up to 1600x1200
24.1-inch LCD flat panel monitor Supports resolutions up to 1920x1200
TABLE 1-2 Sun Blade 150 System Physical Dimensions
Width Height Depth
17.52 inches
(44.5 cm)
4.65 inches
(11.8 cm)
18.00 inches
(45.7 cm)
