xvii
Tables
TABLE 1-1 Supported Sun Monitors 1–4
TABLE 1-2 Sun Blade 150 System Physical Dimensions 1–4
TABLE 1-3 Back Panel Description and Connector Symbols 1–6
TABLE 1-4 Sun Blade 150 Replaceable Components 1–8
TABLE 4-1 Internal Drives Identification 4–3
TABLE 4-2 DIMM Physical Memory Address 4–5
TABLE 8-1 Flash PROM Jumper Settings 8–15
TABLE A-1 Sun Blade 150 Physical Specifications A–1
TABLE A-2 Sun Blade 150 System Electrical Specifications A–2
TABLE A-3 Acoustic Specifications A–2
TABLE A-4 Sun Blade 150 System Environmental Requirements A–3
TABLE B-1 Power Supply Connector J501 Pin Assignments B–2
TABLE B-2 Power Supply Connector J505 Pin Assignments B–3
TABLE B-3 USB Connector J17, J18 Pin Assignments B–4
TABLE B-4 IEEE 1394 Connector J20, J30 Pin Assignments B–5
TABLE B-5 TPE Connector J19 Pin Assignments B–6
TABLE B-6 TPE UTP-5 Cables B–7
TABLE B-7 Serial Port Connector J36 Pin Assignments B–8
TABLE B-8 Riser Board Serial Port Connector J13 Pin Assignments B–9
TABLE B-9 Parallel Port Connector J9 Pin Assignments B–12
