Chapter 4 Troubleshooting Procedures 4-3
Action
Replace the drive indicated by the failure message. The operating system
identifies the internal drives as shown in
TABLE 4-1.
Note The # symbol in the operating environment address examples can be a
numeral between 0 and 7 and describes the slice or partition on the drive.
Symptom
Hard drive, CD-ROM, or DVD-ROM drive fails to respond to commands.
Action
Test the drive response to the probe-ide command as follows:
1. To bypass POST, type setenv diag-switch? false at the system ok prompt.
2. At the system ok prompt, type:
If the hard drive responds correctly to the probe-ide command, the message
shown in
CODE EXAMPLE 4-4 on page 4-7 is displayed, which means that the
system EIDE controller has successfully probed the device. This is an indication
that the motherboard is operating correctly.
If an optional hard drive is installed and one drive does not respond to the EIDE
controller probe but the other does, replace the unresponsive drive.
TABLE 4-1 Internal Drives Identification
Operating
Environment
Address
Drive Physical Location and
Target Cable Labels
Required Riser Board
Connection
c0t0d0s# Primary hard drive,
target 0
Primary HDD IDE1, J504
*
* A three-way cable connects the Primary Hard Drive, and the CD-ROM or DVD-ROM to the riser board at
connector IDE1, (J504). See the illustrations in Section 7.3, Hard Drives on page 7-6.
c0t6d0s# CD-ROM or DVD-ROM
drive, target 1
CD/DVD IDE1, J504
*
c0t1d0s# Secondary hard drive,
target 2(optional)
Secondary HDD IDE2, J503
ok% reset-all
ok% probe-ide
