B.3 IEEE 1394 Connector
Two IEEE 1394 connectors are located on the back panel.
FIGURE B-4 IEEE 1394 Connector J20, J30 Pin Configuration
TABLE B-4 IEEE 1394 Connector J20, J30 Pin Assignments
Pin Signal Name Description
1 P1394_EX_BUSPOWER Bus power
2 Gnd Ground
3 CM_P1394_TPB1_OUT_N
4 CM_P1394_TPB1_OUT_P
5 CM_P1394_TPA1_OUT_N
6 CM_P1394_TPA1_OUT_P
1
5
3
2
6
4
