Appendix B Signal Descriptions B-13
16 INIT_L Driven low by the host to reset peripheral.
17 PAR_IN_L Set low by the host to select peripheral device for forward
channel transfer. Set high to indicate bus direction is from
peripheral to host.
18 Signal ground Signal ground
19 Signal ground Signal ground
20 Signal ground Signal ground
21 Signal ground Signal ground
22 Signal ground Signal ground
23 Signal ground Signal ground
24 Signal ground Signal ground
25 Signal ground Signal ground
TABLE B-9 Parallel Port Connector J9 Pin Assignments (Continued)
