Alarm No.
Alarm text
Function
Priority Stop Delay Resetting
0 = Blocked 0 = In operat. s = second 0 = manual
A = A alarm 1 = Stop m = minute 1 = automatic
B = B alarm h=hour
33:15 LOCK FUNCTION TRIPPED
Contact Swegon or their representative.
– – – 0
6)
Alarm group 34: External controls
34:1 EXTERNAL CONTROL, I/O MODULE NO. 3 COMMUNICA-
TION ERROR
The air handling unit's control unit cannot establish correct
communication with I/O module No. 3 for external control.
B 0
3)
10 s 1
34:2 EXTERNAL CONTROL, I/O MODULE NO. 6 COMMUNICA-
TION ERROR
The air handling unit's control unit cannot establish correct
communication with I/O module No. 6 for external control.
B 0
3)
10 s 1
Alarm group 35: Booster diffusers
35:1 BOOSTER AIR TERMINALS, I/O MODULE NO. 8 COMMUNI-
CATION ERROR
The air handling unit's control unit cannot establish correct
communication with I/O module No. 8 for Booster diffusers.
B 0
3)
10 s 1
Alarm group 36: External communication, I/O-modules
36:1 EXTERNAL COMMUNICATION, I/O MODULE NO. A COM-
MUNICATION ERROR
The air handling unit's control unit cannot establish correct
communication with I/O module No. A.
B 0
3)
10 s 1
36:2 EXTERNAL COMMUNICATION, I/O MODULE NO. A TEM-
PERATURE SENSOR NO. 1 DEFECTIVE
I/O-module A, temperature sensor 1, is defective or is not
connected.
B 0
3)
3 s 1
36:3 EXTERNAL COMMUNICATION, I/O MODULE NO. A TEM-
PERATURE SENSOR NO. 2 DEFECTIVE
I/O-module A, temperature sensor 2, is defective or is not
connected.
B 0
3)
3 s 1
36:6 EXTERNAL COMMUNICATION, I/O MODULE NO. B COM-
MUNICATION ERROR
The air handling unit's control unit cannot establish correct
communication with I/O module No. B.
B 0
3)
10 s 1
36:7 EXTERNAL COMMUNICATION, I/O MODULE NO. B TEM-
PERATURE SENSOR NO. 1 DEFECTIVE
I/O-module B, temperature sensor 1, is defective or is not
connected.
B 0
3)
3 s 1
36:8 EXTERNAL COMMUNICATION, I/O MODULE NO. B TEM-
PERATURE SENSOR NO. 2 DEFECTIVE
I/O-module B, temperature sensor 2, is defective or is not
connected.
B 0
3)
3 s 1
36:11 EXTERNAL COMMUNICATION, I/O MODULE NO. C COM-
MUNICATION ERROR
The air handling unit's control unit cannot establish correct
communication with I/O module No. C.
B 0
3)
10 s 1
36:12 EXTERNAL COMMUNICATION, I/O MODULE NO. C TEM-
PERATURE SENSOR NO. 1 DEFECTIVE
I/O-module C, temperature sensor 1, is defective or is not
connected.
B 0
3)
3 s 1
36:13 EXTERNAL COMMUNICATION, I/O MODULE NO. C TEM-
PERATURE SENSOR NO. 2 DEFECTIVE
I/O-module C, temperature sensor 2, is defective or is not
connected.
B 0
3)
3 s 1
