Status
Extra regulation
sequence 1/2
6.4.12 Cool
6.4.12.1 Status
All the relevant values can be read here. Used for performance
checks.
6.4.12.2 Extra regulation sequences 1 and 2
Used for extra regulation functions controlled by a 0-10 V (10-0
V) signal with ordinary temperature regulation sequence.
The function can be used for utilizing existing heating or cooling
sources, such as from a chiller. The function can also be used for
an extra air heater or air cooler.
It can also be used for controlling dampers for recirculation, if
required. In these cases, an inverted 10-0 V output is used.
Recirculation control is used for the TBBD mixing section (GOLD
SD only) The 10-0 V inverted output should be in the On posi-
tion.
The maximum output signal can be limited from 100% down to
0 %.
The output signal of the extra regulation sequence is controlled
from the TBIQ-3-2 IQlogic
+
module accessory, see separate instal-
lation instructions.
When the SMART Link DX function is selected, the extra regula-
tion sequence is automatically activated. The extra regulation
sequence cannot then be used for any other functionality. An
IQlogic+ module is not required (alarm for missing module is
blocked).
Settings:
Value Setting
range
Factory
setting
Extra regulation sequence
1/2
Inactive/Heat/Cool/
Heat and cool
Inactive
Output inverse 10-0V On/Off Off
Recirculation control On/Off Off
Max. output signal 0-100% 100%
Periodic operation of pump On/Off On
Periodic operation of valve On/Off On
Periodic operation interval 0-168 hrs. 24 hrs.
Periodic operation period 0-60 min. 3 min.
Pump alarm Inactive/Alarm
on open contact/
Alarm on closed
contact/Contactor
function
Inactive
