6.4.2.8 Regulation sequence
Heating mode
The mutual order for the heating mode regulation sequence can
be selected as specified below.
Functions that have not been selected have no effect on the
relevant regulation sequence.
Value Setting
range
Factory
setting
Heating mode 1/2/3/4/5/6* 1
* 1 = HX - Extra regulation sequence - ReCO
2
- Reheating -
Down regulation of fan
2 = HX - Extra regulation sequence - Reheating - ReCO
2
-
Down regulation of fan
3 = HX - Reheating - ReCO
2
- Extra regulation sequence -
Down regulation of fan
4 = HX - Reheating - Extra regulation sequence - ReCO
2
-
Down regulation of fan
5 = HX - ReCO
2
- Reheating - Extra regulation sequence -
Down regulation of fan
6 = HX - ReCO
2
- Extra regulationsequence - Reheating -
Down regulation of fan
HX (heat exchanger):
The temperature efficiency of the air handling unit’s heat
exchanger is modulated to provide max. heat recovery.
Extra regulation sequence:
Used in the heating mode for air heater (if required), air recircula-
tion damper, etc.
ReCO
2
:
Recirculated air is variably mixed in up to the lowest permissible
supply airflow. Assumes inclusion of the TCBR air recirculation
section accessory.
Reheating:
Air heater for reheating provides heating capacity.
Down regulation of fan:
Down regulation can be selected for supply air only or supply air
and extract air.
Regulation sequence
