Alarm No.
Alarm text
Function
Priority Stop Delay Resetting
0 = Blocked 0 = In operat. s = second 0 = manual
A = A alarm 1 = Stop m = minute 1 = automatic
B = B alarm h=hour
Alarm group 1: Fire alarm
1:1 EXTERNAL FIRE ALARM NO. 1 TRIPPED
For the fire protection function connected to terminals 6-7.
A
1)
1 3 s 0
1:2 EXTERNAL FIRE ALARM NO. 2 TRIPPED
For the fire protection function connected to terminals 8-9.
A
1)
1 3 s 0
1:3 INTERNAL FIRE ALARM TRIPPED
The air handling unit’s supply air sensor measures more than
70 °C and/or its extract air temperature sensor measures
more than 50 °C.
The function must be activated manually.
A
1)
1 3 s 0
Alarm group 2: External alarm
2:1 EXTERNAL ALARM NO. 1 TRIPPED
External alarm, connected to control unit terminals 10-11,
has tripped..
A 1
3)
1 s
2)
0
2:2 EXTERNAL ALARM NO. 2 TRIPPED
External alarm, connected to control unit terminals 12-13,
has tripped..
B 0
3)
1 s
2)
0
Alarm group 3: Pre-heating
3:1 PRE-HEAT, I/O MODULE NO. 9 COMMUNICATION ERROR
The air handling unit’s control unit cannot establish correct
communication with I/O module No. 9 for pre-heating.
A 0
3)
10 s 1
3:2 PRE-HEAT, OVERHEATING PROTECTION FOR ELECTRIC AIR
HEATER TRIPPED
The overheating protection, electric air heater, has tripped.
A
1)
0
3)
10 s 0
3:3 PRE-HEAT, FROST GUARD TRIPPED
Frost guard temperature sensor measures temperature less
than preset alarm limit.
Factory setting: 7 °C.
A
1)
1 5 s 0
3:4 PRE-HEAT, FROST GUARD TEMPERATURE SENSOR DEFEC-
TIVE
Frost guard temperature sensor is defective or is not con-
nected.
A
1)
1 3 s 1
3:5 PRE-HEAT, TEMPERATURE SENSOR DEFECTIVE
Sensor is defective or is not connected.
A 0
3)
3 s 1
3:6 PRE-HEAT, VALVE MONITORING TRIPPED
Valve actuator, air heater for water is defective.
A 0
3)
10 m 0
3:7 PRE-HEAT, TEMPERATURE BELOW SET POINT ALARM LIMIT
Temperature is below preset set point longer than 20 min-
utes.
A 0
3)
20 m 0
3:8 PRE-HEAT, ALARM INPUT TRIPPED
Alarm input pre-heat has tripped.
A 0 20 s 0
Alarm group 4: Extra regulation sequence
4:1 EXTRA REGULATION SEQUENCE 1, I/O-MODULE No E
COMMUNICATION ERROR
The air handling unit's control unit cannot establish correct
communication with I/O module No. E for extra regulation
sequence.
A 0
3)
10 s 1
4:2 EXTRA REGULATION SEQUENCE 1, OVERHEATING PROTEC-
TION FOR ELECTRIC AIR HEATER TRIPPED
Overheating protection, electric air heater, has tripped.
A
1)
0
3)
10 s 0
