Alarm No.
Alarm text
Function
Priority Stop Delay Resetting
0 = Blocked 0 = In operat. s = second 0 = manual
A = A alarm 1 = Stop m = minute 1 = automatic
B = B alarm h=hour
11:9 OUTDOOR TEMPERATURE SENSOR NO. A DEFECTIVE
Outdoor temperature sensor A is defective or is not con-
nected.
B 0
3)
10 s 1
11:10 OUTDOOR TEMPERATURE SENSOR NO. B DEFECTIVE
Outdoor temperature sensor B is defective or is not con-
nected.
B 0
3)
10 s 1
11:11 OUTDOOR TEMPERATURE SENSOR NO. C DEFECTIVE
Outdoor temperature sensor C is defective or is not con-
nected.
B 0
3)
10 s 1
11:12 OUTDOOR TEMPERATURE SENSOR NO. D DEFECTIVE
Outdoor temperature sensor D is defective or is not con-
nected.
B 0
3)
10 s 1
11:13 ROOM TEMPERATURE VIA COMMUNICATION, COMMUNI-
CATION ERROR
The air handling unit’s control unit is not receiving any tem-
perature reading via the external communication interface
within the preset time limit.
B 0
3)
5 m
2)
1
11.14 Xzone, ROOM TEMPERATURE VIA COMMUNICATION, COM-
MUNICATION ERROR
The air handling unit’s control unit is not receiving any tem-
perature reading via the external communication interface
within the preset time limit.
B 0
3)
5 m
2)
1
11:15 OUTDOOR TEMPERATURE VIA COMMUNICATION, COM-
MUNICATION ERROR
The air handling unit’s control unit is not receiving any tem-
perature reading via the external communication interface
within the preset time limit.
B 0
3)
5 m
2)
1
Alarm group 12: AHU, temperature diff.
12:1 SUPPLY AIR TEMPERATURE BELOW SET POINT ALARM LIMIT
The supply air temperature is lower than the preset set point
(ERS, ORS, ORE and Supply air regulation) or has deviated
from the supply air controller’s current set point (Extract air
regulation) longer than 20 minutes.
A 1
3)
20 m 0
12:2 SUPPLY AIR TEMPERATURE ABOVE SET POINT ALARM LIMIT
The supply air temperature is above the preset set point
(ERS, ORS, ORE and Supply air regulation) or has deviated
from the supply air controller’s current set point (Extract air
regulation) longer than 20 minutes.
B 0
3)
20 m 0
12:6 EXTRACT AIR TEMPERATURE BELOW ALARM LIMIT
The extract air temperature is below preset alarm limit for
more than 20 minutes.
A 1
3)
20 m 0
12:11 TEMPERATURE PROTECTION BELOW ALARM LIMIT
The temperature protection reading is below preset alarm
limit.
A 1
3)
30 s
2)
0
Alarm group 13: Humidity/VOC
13:1 HUMIDIFICATION, I/O MODULE NO. 4 COMMUNICATION
ERROR
The air handling unit's control unit cannot establish correct
communication with I/O module No. 4 for humidity.
B 0
3)
10 s 1
13:2 SUPPLY AIR HUMIDITY SENSOR DEFECTIVE
The humidity sensor in the supply air duct is defective or is
not connected.
A 0
3)
10 s 1
13:3 EXTRACT AIR HUMIDITY SENSOR DEFECTIVE
The humidity sensor in the extract air duct is defective or is
not connected.
A 0
3)
10 s 1
