Booster diffusers
6.4.1.9 Booster diffusers
The function for Booster diffusers is used for controlling the air
damper inside the air terminal and can be activated for heat-
ing or cooling. Heating or cooling is modulated depending on
whether the supply air is warmer or colder than the room/extract
air. An indicator is displayed if heating or cooling is active.
The IQlogic
+
module, TBIQ-3-2, accessory is required.
Value Setting
range
Factory
setting
Booster diffusers On/Off Off
6.4.1.10 Automatic operation
Density-corrected airflow
The density of the air is different at different temperatures. This
means that a specific volume of air changes at various air den-
sities. The AHU automatically corrects this, so that correct air
volume is always obtained.
The control equipment always displays the corrected airflow.
Pressure balance corrected extract airflow
The extract airflow is corrected by continuously measuring the
pressure balance across the rotary heat exchanger. The extract
airflow is guaranteed with consideration given to the air purging
and leakage air flow.
