Alarm No.
Alarm text
Function
Priority Stop Delay Resetting
0 = Blocked 0 = In operat. s = second 0 = manual
A = A alarm 1 = Stop m = minute 1 = automatic
B = B alarm h=hour
4:3 EXTRA REGULATION SEQUENCE 1, FROST GUARD TRIPPED
Frost guard temperature sensor measures temperature less
than preset alarm limit.
Factory setting: 7 °C.
A
1)
1 5 s 0
4:4 EXTRA REGULATION SEQUENCE 1, FROST GUARD TEMPER-
ATURE SENSOR DEFECTIVE
Frost guard temperature sensor is defective or is not con-
nected.
A
1)
1 3 s 1
4:5 EXTRA REGULATION SEQUENCE 1, VALVE MONITORING
TRIPPED
Valve actuator, air heater for water, is defective.
B 0
3)
10 m 0
4:6 EXTRA REGULATION SEQUENCE 1, ALARM INPUT TRIPPED
Alarm input extra regulation sequence has tripped.
A 0 20 s 0
4:7 EXTRA REGULATION SEQUENCE 1, TEMPERATURE PROTEC-
TION VIA COMMUNICATION, COMMUNICATION ERROR
The air handling unit’s control unit is not receiving any tem-
perature reading via the external communication interface
within the preset time limit.
B 0 5 m 1
4:9 EXTRA REGULATION SEQUENCE 2, I/O-MODULE No F
COMMUNICATION ERROR
The air handling unit's control unit cannot establish correct
communication with I/O module No. E for extra regulation
sequence.
A 0
3)
10 s 1
4:10 EXTRA REGULATION SEQUENCE 2, OVERHEATING PROTEC-
TION FOR ELECTRIC AIR HEATER TRIPPED
Overheating protection, electric air heater, has tripped.
A
1)
0
3)
10 s 0
4:11 EXTRA REGULATION SEQUENCE 2, FROST GUARD TRIPPED
Frost guard temperature sensor measures temperature less
than preset alarm limit.
Factory setting: 7 °C.
A
1)
1 5 s 0
4:12 EXTRA REGULATION SEQUENCE 2, FROST GUARD TEMPER-
ATURE SENSOR DEFECTIVE
Frost guard temperature sensor is defective or is not con-
nected.
A
1)
1 3 s 1
4:13 EXTRA REGULATION SEQUENCE 2, VALVE MONITORING
TRIPPED
Valve actuator, air heater for water, is defective.
B 0
3)
10 m 0
4:14 EXTRA REGULATION SEQUENCE 2, ALARM INPUT TRIPPED
Alarm input extra regulation sequence has tripped.
A 0 20 s 0
Alarm group 5: Reheating
5:1 REHEAT, OVERHEATING PROTECTION FOR ELECTRIC AIR
HEATER TRIPPED
The overheating protection, electric air heater, has tripped.
A
1)
0
3)
10 s 0
5:2 REHEAT, FROST GUARD TRIPPED
Frost guard temperature sensor measures temperature less
than preset alarm limit.
Factory setting: 7 °C.
A
1)
1 5 s 0
5:3 REHEAT, FROST GUARD TEMPERATURE SENSOR DEFECTIVE
Frost guard temperature sensor is defective or is not con-
nected.
A
1)
1 3 s 1
5:4 REHEAT, VALVE MONITORING TRIPPED
Valve actuator, air heater for water is defective.
B 0
3)
10 m 0
