SMART Link
6.4.14 SMART Link
The SMART Link function is intended for use for optimum con-
trol of the temperature and operation as well as the reading of
alarms and the values for a Swegon chiller/heat pump.
For more information concerning waterborne heat pumps/chill-
ers, see the Guide to the SMART Link/AQUA Link Functions.
For more information concerning DX heat pumps/chillers (Celest
+
LE), see the Guide to the SMART Link DX (GOLD RX only) Func-
tions.
Settings:
Value Setting
range
Factory
setting
Type of unit Inactive/
Water, heat
pump/
Water, chiller/
Water, reversible/
DX, heat pump/
DX, chiller/
DX, reversible
Inactive
Water
Heated water (set point) 10 - 80°C
1)
40°C
Heated water, diff. 1 - 10 K 3 K
Chilled water (set point) 0 - 20°C
1)
12°C
Chilled water, diff. 1 - 10 K 2 K
Outdoor air limit
(not applicable to the chiller)
-50 – +50°C -20°C
Optimize On/Off Off
Optimizing cooling
regulation speed
0.01 - 6.00 K/min 0.3 K/min
Optimizing heating
regulation speed
0.01 - 6.00 K/min 0.3 K/min
Valve limit, lower 5 - 90% 75
Valve limit, upper 70 - 100% 95
Delay 30 - 3200 60
AQUA Link On/Off Off
Pump alarm Inactive/Alarm on
closed contact/
Alarm on open
contact/Contac-
tor function
Inactive
DX
Number of connected units
(Celest
+
)
1-4 1
Comfort mode, duration 0-180 min 30 min
Outdoor air limit
(not applicable to the chiller)
-50 – +50°C -20°C
Defrost delay 5 - 900 s 180 s
Dead band supply air temp. 0,0 - 5,0K 1,0K
Stabilization time 60 - 600 s 240 s
1)
Min. and max. limited by preset values in the chiller/heat
pump..
