GB.GOLDSKE.160901
www.swegon.com 99
We reserve the right to alter specifications without notice.
Alarm No.
Alarm text
Function
Priority Stop Delay Resetting
0 = Blocked 0 = In operat. s = second 0 = manual
A = A alarm 1 = Stop m = minute 1 = automatic
B = B alarm h=hour
31:1 PRESSURE REGULATION, SUPPLY AIR PRESSURE SENSOR NO.
5 COMMUNICATION ERROR
The air handling unit's control unit cannot establish correct
communication with the duct pressure sensor in the supply
air. Applies only to pressure regulation of the supply air.
A 1
3)
10 s 1
31:2 PRESSURE REGULATION, SUPPLY AIR PRESSURE BELOW SET
POINT ALARM LIMIT
The duct pressure has gone below its set point by more that
10%, during a longer period than 20 minutes ( if pressure
sensors are connected).
B 0
3)
20 m 0
31:3 PRESSURE REGULATION, SUPPLY AIR PRESSURE ABOVE SET
POINT ALARM LIMIT
The supply air duct pressure has exceeded its set point by
more that 10%, during a longer period than 20 minutes (if
pressure sensors are connected).
B 0
3)
20 m 0
31:6 PRESSURE REGULATION, EXTRACT AIR PRESSURE SENSOR
NO. 6 COMMUNICATION ERROR
The air handling unit's control unit cannot establish correct
communication with the duct pressure sensor in the extract
air. Applies only to pressure regulation of the extract air.
A 1
3)
10 s 1
31:7 PRESSURE REGULATION, EXTRACT AIR PRESSURE BELOW
SET POINT ALARM LIMIT
The extract air duct pressure has gone below its set point by
more that 10%, during a longer period than 20 minutes (if
pressure sensors are connected).
B 0
3)
20 m 0
31:8 PRESSURE REGULATION, EXTRACT AIR PRESSURE ABOVE
SET POINT ALARM LIMIT
The extract air duct pressure has exceeded its set point by
more that 10%, during a longer period than 20 minutes (if
pressure sensors are connected).
B 0
3)
20 m 0
Alarm group 32: ReCO
2
/Intermittent night heating
32:1 ReCO
2
, I/O MODULE NO. 0 COMMUNICATION ERROR
The air handling unit's control unit cannot establish correct
communication with I/O module no. 0.
A 0
3)
10 s 1
32:2 ReCO
2
, PRESSURE SENSOR NO. 0 COMMUNICATION ERROR
The air handling unit's control unit cannot establish correct
communication with the pressure sensor.
A 0
3)
10 s 1
32:3 ReCO
2
/INTERMITTENT NIGHT HEATING, RECIRCULATED AIR
DAMPER MONITORING TRIPPED
The damper actuator does not move to the right position.
The position-confirming output signal from the damper is
not the same as the input control signal.
B 0
3)
10 m 0
32:4 ReCO
2
, OUTDOOR AIR DAMPER MONITORING TRIPPED
The damper actuator does not move to the right position.
The position-confirming output signal from the damper is
not the same as the input control signal.
B 0
3)
10 m 0
Alarm group 33: Service
33:1 PERIOD BETWEEN SERVICING PAST ALARM LIMIT
The preset service period has expired.
If the alarm is RESET via the hand-held terminal, the alarm
will be initiated again after 7 days.
A new service period can be set and reset under ALARM
SETTINGS.
B 0
3)
5 s
2)
0
