Alarm No.
Alarm text
Function
Priority Stop Delay Resetting
0 = Blocked 0 = In operat. s = second 0 = manual
A = A alarm 1 = Stop m = minute 1 = automatic
B = B alarm h=hour
Alarm group 10: AHU, internal temperature sensor
10:1 SUPPLY AIR TEMPERATURE SENSOR DEFECTIVE
Supply air sensor is defective or is not connected.
A 1
3)
3 s 1
10:2 SUPPLY AIR TEMPERATURE SENSOR FOR DENSITY COMPEN-
SATION DEFECTIVE
Supply air sensor in the supply air fan intake cannot establish
correct communication or shows an incorrect value.
B 0
3)
3 s 1
10:3 EXTRACT AIR TEMPERATURE SENSOR DEFECTIVE
Extract air sensor is defective or is not connected.
A 1
3)
3 s 1
10:4 EXTRACT AIR TEMPERATURE SENSOR FOR DENSITY COM-
PENSATION DEFECTIVE (GOLD RX/PX/CX)
Temperature sensor in extract air fan intake cannot establish
correct communication or shows incorrect value.
GOLD RX
Exhaust air regulation has been selected, but the tempera-
ture sensor in the exhaust air is defective or is not con-
nected.
B 0
3)
3 s 1
10:5 EXTRACT AIR TEMPERATURE SENSOR FOR HEAT EXCHANG-
ER DEFROSTING DEFECTIVE
Temperature sensor, for heat exchanger defrosting is defec-
tive.
A 1
3)
10 s 1
10:6 EXTRACT AIR TEMPERATURE SENSOR FOR DENSITY COM-
PENSATION IN SD AHU DEFECTIVE
Temperature sensor in extract air fan intake cannot establish
correct communication or shows incorrect value.
A 1
3)
10 s 1
10:7 EXTRACT AIR DUCT TEMPERATURE SENSOR DEFECTIVE
The temperature sensor in the extract air duct is defective or
is not connected.
A 1
3)
10 s 1
10:10 OUTDOOR AIR TEMPERATURE SENSOR DEFECTIVE (GOLD
SD)
Outdoor temperature sensor is defective or is not connected.
B 0
3)
3 s 1
Alarm group 11: External temperature sensors
11:1 ROOM TEMPERATURE SENSOR NO. 1 DEFECTIVE
Room temperature sensor 1 is defective or is not connected.
B 0
3)
10 s 1
11:2 ROOM TEMPERATURE SENSOR NO. 2 DEFECTIVE
Room temperature sensor 2 is defective or is not connected.
B 0
3)
10 s 1
11:3 ROOM TEMPERATURE SENSOR NO. 3 DEFECTIVE
Room temperature sensor 3 is defective or is not connected.
B 0
3)
10 s 1
11:4 ROOM TEMPERATURE SENSOR NO. 4 DEFECTIVE
Room temperature sensor 4 is defective or is not connected.
B 0
3)
10 s 1
11:5 Xzone, ROOM TEMPERATURE SENSOR NO. 5 DEFECTIVE
Xzone room temperature sensor 5 is defective or is not con-
nected.
B 0
3)
10 s 1
11:6 Xzone, ROOM TEMPERATURE SENSOR NO. 6 DEFECTIVE
Xzone room temperature sensor 6 is defective or is not con-
nected.
B 0
3)
10 s 1
11:7 Xzone, ROOM TEMPERATURE SENSOR NO. 7 DEFECTIVE
Xzone room temperature sensor 7 is defective or is not con-
nected.
B 0
3)
10 s 1
11:8 Xzone, ROOM TEMPERATURE SENSOR NO. 8 DEFECTIVE
Xzone room temperature sensor 8 is defective or is not con-
nected.
B 0
3)
10 s 1
