Alarm No.
Alarm text
Function
Priority Stop Delay Resetting
0 = Blocked 0 = In operat. s = second 0 = manual
A = A alarm 1 = Stop m = minute 1 = automatic
B = B alarm h=hour
Alarm group 6: Xzone I/O-module no. A
6:1 Xzone, I/O-MODULE NO. A COMMUNICATION ERROR
The air handling unit's control unit cannot establish correct
communication with I/O module No. A for Xzone.
A 0
3)
10 s 1
6:2 Xzone, OVERHEATING PROTECTION FOR ELECTRIC AIR
HEATER TRIPPED
The overheating protection, electric air heater, has tripped.
A
1)
0
3)
10 s 0
6:3 Xzone, FROST GUARD TRIPPED
Frost guard temperature sensor measures temperature less
than preset alarm limit.
Factory setting: 7 °C.
A
1)
1 5 s 0
6:4 Xzone, FROST GUARD TEMPERATURE SENSOR DEFECTIVE
Frost guard temperature sensor is defective or is not con-
nected.
A
1)
1 3 s 1
6:5 Xzone, SUPPLY AIR TEMPERATURE SENSOR DEFECTIVE
Supply air sensor is defective or is not connected.
A 1
3)
3 s 1
6:6 Xzone, HEATING VALVE MONITORING TRIPPED
Valve actuator, air heater for water is defective.
B 0
3)
10 m 0
6:7 Xzone, SUPPLY AIR TEMPERATURE BELOW SET POINT
ALARM LIMIT
The supply air temperature is below the preset set point
(ERS and Supply air regulation) or Min SA temp (Extract air
regulation) longer than 20 minutes.
A 0
3)
20 m 0
6:8 Xzone, SUPPLY AIR TEMPERATURE ABOVE SET POINT
ALARM LIMIT
The supply air temperature is above the preset set point
(ERS and Supply air regulation) or Max. SA temp (Extract air
regulation) longer than 20 minutes.
B 0
3)
20 m 0
6:9 Xzone, HEAT, ALARM INPUT TRIPPED
Alarm input Xzone heat has tripped.
A 0 20 s 0
Alarm group 7: Xzone I/O-module no. B
7:1 Xzone, I/O-MODULE NO. B COMMUNICATION ERROR
The air handling unit's control unit cannot establish correct
communication with I/O module No. B for Xzone.
A 0
3)
10 s 1
7:2 Xzone, EXTRACT AIR TEMPERATURE SENSOR DEFECTIVE
Extract air sensor is defective or is not connected.
A 1
3)
3 s 1
7:3 Xzone, COOLING VALVE MONITORING TRIPPED
Valve actuator, air cooler for water is defective.
B 0
3)
10 m 0
7:4 Xzone, EXTRACT AIR TEMPERATURE SENSOR BELOW SET
POINT ALARM LIMIT
The extract air temperature is below preset alarm limit for
more than 20 minutes.
A 0
3)
20 m 0
7:5 Xzone, COOL, ALARM INPUT 1 TRIPPED
Alarm input 1 Xzone cool has tripped.
A 0 20 s 0
7:6 Xzone, COOL, ALARM INPUT 2 TRIPPED
Alarm input 2 Xzone cool has tripped.
A 0 20 s 0
Alarm group 8: Cooling
8:5 COOLING, VALVE MONITORING TRIPPED
Valve actuator, air cooler, is defective.
B 0
3)
10 s 0
Alarm group 9: Spare
