Alarm No.
Function
Factory-preset valuee Adjusted value
Priority Effect Priority Effect
0 = Blocked 0 = In oper. 0 = Blocked 0 = In oper.
A = alarm A 1 = Stop A = A alarm 1 = Stop
B = B alarm B = B alarm
10:2 Supply air temperature sensor for density compensation defective B 0
3)
10:3 Extract air temperature sensor defective A 1
3)
10:4 Extract air temperature sensor for density compensation defective
(RX/PX/CX)
B 0
3)
10:5 Extract air temperature sensor for heat exchanger defrosting defective A 1
3)
10:6 Extract air temperature sensor for density compensation in SD AHU defec-
tive
A 1
3)
10:10 Outdoor air temperature sensor defective (GOLD SD) B 0
3)
11:1 Room temperature sensor no. 1 defective B 0
3)
11:2 Room temperature sensor no. 2 defective B 0
3)
11:3 Room temperature sensor no. 3 defective B 0
3)
11:4 Room temperature sensor no. 4 defective B 0
3)
11:5 Xzone, room temperature sensor no. 5 defective B 0
3)
11:6 Xzone, room temperature sensor no. 6 defective B 0
3)
11:7 Xzone, room temperature sensor no. 7 defective B 0
3)
11:8 Xzone, room temperature sensor no. 8 defective B 0
3)
11:9 Outdoor temperature sensor no. A defective B 0
3)
11:10 Outdoor temperature sensor no. B defective B 0
3)
11:11 Outdoor temperature sensor no. C defective B 0
3)
11:12 Outdoor temperature sensor no. D defective B 0
3)
11:13 Room temperature via communication, communication error
2)
B 0
3)
11:14 Xzone, room temperature via communication, communication error
2)
B 0
3)
11:15 Outdoor temperature via communication, communication error
2)
B 0
3)
12:1 Supply air temperature below set point alarm limit A 1
3)
12:2 Supply air temperature above set point alarm limit B 0
3)
12:6 Extract air temperature below alarm limit A 1
3)
12:11 Temperature protection below alarm limit
2)
A 1
3)
13:1 Humidification, I/O module no. 4 communication error B 0
3)
13:2 Supply air humidity sensor defective A 0
3)
13:3 Extract air humidity sensor defective A 0
3)
13:9 Humidifier, alarm output tripped A 0
3)
13:11 VOC sensor communication error B 0
3)
13:12 VOC sensor, internal communication error B 0
3)
13:13 VOC sensor, internal error B 0
3)
13:14 VOC sensor, level below/above set point alarm limit B 0
3)
15:1 plate heat exchanger, I/O module no. 2 communication error A 1
3)4)
15:2 Plate heat exchanger, temperature sensor no. 1 defective A 1
3)4)
15:3 Plate heat exchanger, temperature sensor no. 2 defective A 1
3)4)
15:4 Plate heat exchanger, damper monitoring tripped A 0
3)4)
15:7 Plate heat exchanger, I/O module no. 3 communication error A 1
15:8 Plate heat exchanger, bypass damper monitoring tripped A 0
15:9 Plate heat exchanger, damper no. 1 monitoring tripped A 0
15:10 Plate heat exchanger, damper no. 2 monitoring tripped A 0
15:11 Plate heat exchanger, I/O module no. 3 communication error A 1
15:12 Plate heat exchanger, bypass damper monitoring tripped A 0
15:14 Plate heat exchanger, defrosting sensor no. C communication error B 0
15:15 Plate heat exchanger, defrosting pressure over alarm limit B 1
16:1 Coil heat exchanger, I/O module no. 1 communication error A 1
3)4)
