Alarm No.
Function
Factory-preset valuee Adjusted value
Priority Effect Priority Effect
0 = Blocked 0 = In oper. 0 = Blocked 0 = In oper.
A = alarm A 1 = Stop A = A alarm 1 = Stop
B = B alarm B = B alarm
1:1 External fire alarm no. 1 tripped A
1)
1
1:2 External fire alarm no. 2 tripped A
1)
1
1:3 Internal fire alarm tripped A
1)
1
2:1 External alarm no. 1 tripped
2)
A 1
3)
2:2 External alarm no. 2 tripped
2)
B 0
3)
3:1 Preheating, I/O module no. 9 communication error A 0
3)
3:2 Preheating, overheating protection for electric air heater tripped A
1)
0
3)
3:3 Pre-heating, frost guard tripped A
1)
1
3:4 Pre-heating, frost guard temperature sensor defective A
1)
1
3:5 Pre-heating, temperature sensor defective A 0
3)
3:6 Pre-heating, valve monitoring tripped B 0
3)
3:7 Pre-heating, temperature below set point alarm limit A 0
3)
3:8 Pre-heat, alarm input tripped A 0
4:1 Extra regulation sequence 1, I/O module no. E communication error A 0
3)
4:2 Extra regulation sequence 1, overheating protection for electric air heater
tripped
A
1)
0
3)
4:3 Extra regulation sequence 1, frost guard tripped A
1)
1
4:4 Extra regulation sequence 1, fost guard temperature sensor defective A
1)
1
4:5 Extra regulation sequence 1, valve monitoring tripped B 0
3)
4:6 Extra regulation sequence 1, alarm input tripped A 0
4:7 Extra regulation sequence 1, temperature protection via communication,
communication error
B 0
4:9 Extra regulation sequence 2, I/O module no. F communication error A 0
3)
4:10 Extra regulation sequence 2, overheating protection for electric air heater
tripped
A
1)
0
3)
4:11 Extra regulation sequence 2, frost guard tripped A
1)
1
4:12 Extra regulation sequence 2, fost guard temperature sensor defective A
1)
1
4:13 Extra regulation sequence 22, valve monitoring tripped B 0
3)
4:14 Extra regulation sequence 1, alarm input tripped A 0
5:1 Reheating, overheating protection for electric air heater tripped A
1)
0
3)
5:2 Reheating, frost guard tripped A
1)
1
5:3 Reheating, frost guard temperature sensor defective A
1)
1
5:4 Reheating, heat valve monitoring tripped B 0
3)
6:1 Xzone I/O-module no. A communication error A 0
3)
6:2 Xzone, overheating protection for electric air heater tripped A
1)
0
3)
6:3 Xzone, frost guard tripped A
1)
1
6:4 Xzone, frost guard temperature sensor defective A
1)
1
6:5 Xzone, supply air temperature sensor defective A 1
3)
6:6 Xzone, heating valve monitoring tripped B 0
3)
6:7 Xzone, supply air temperature below set point alarm limit A 0
3)
6:8 Xzone, supply air temperature above set point alarm limit B 0
3)
6:9 Xzone, heat, alarm input tripped A 0
7:1 Xzone I/O-module no. B communication error A 0
3)
7:2 Xzone, extract air temperature sensor defective A 1
3)
7:3 Xzone, cooling valve monitoring tripped B 0
3)
7:4 Xzone, extract air temperature below set point alarm limit A 0
3)
7:5 Xzone, cool, alarm input 1 tripped A 0
7:6 Xzone, cool, alarm input 2 tripped A 0
8:5 Cooling, valve monitoring tripped B 0
3)
10:1 Supply air temperature sensor defective A 1
3)
