Function Factory-preset value Adjusted value
Inputs / Outputs
External operation, module 6
Digital
output 1,
operating
mode
Inactive
Inactive Air handling unit in operation
AHU in auto op. mode AHU in man. op. mode
AHU in low speed op. mode AHU in high speed operation
A alarm B-alarm
Damper relay Heat exchange
Heat exchanger, defrost. Re-heat
Reheat, cap. red. Heating boost
Morning Boost Intermittent night op.
Air flow down regulation Extra reg. sequ. 1, Heat
Extra reg. sequ. 2, Heat Extra reg. sequ. 1, Cool
Extra reg. sequ. 2, Cool Cooling
Cooling Boost Summer night cool
Supply air fan in operation Extract air fan in operation
Internal fire alarm tripped External fire alarm 1
External fire alarm 2 External fire alarms 1 and 2
Any fire alarm
Digital
output 2,
operating
mode
Inactive
Inactive Air handling unit in operation
AHU in auto op. mode AHU in man. op. mode
AHU in low speed op. mode AHU in high speed operation
A alarm B-alarm
Damper relay Heat exchange
Heat exchanger, defrost. Re-heat
Reheat, cap. red. Heating boost
Morning Boost Intermittent night op.
Air flow down regulation Extra reg. sequ. 1, Heat
Extra reg. sequ. 2, Heat Extra reg. sequ. 1, Cool
Extra reg. sequ. 2, Cool Cooling
Cooling Boost Summer night cool
Supply air fan in operation Extract air fan in operation
Internal fire alarm tripped External fire alarm 1
External fire alarm 2 External fire alarms 1 and 2
Any fire alarm
Digital
X
Inactive
Alarm reset Inactive Alarm reset
Input 1
Stop AYC heating water Stop AYC chilled water Stop AYC heating water S top AYC, chilled water
Digital X
Inactive
Alarm reset Inactive Alarm reset
Input 2
Stop AYC heating water Stop AYC chilled water Stop AYC heating water Stop AYC chilled water
Analogue See Section 6.4.19
Inactive Set point displacement
Input 1
Set point displ., supply air Set point displ., extract air
Analogue See Section 6.4.19
Inactive Set point displacement
Input 2
Set point displ., supply air Set point displ., extract air
