Alarm No.
Alarm text
Function
Priority Stop Delay Resetting
0 = Blocked 0 = In operat. s = second 0 = manual
A = A alarm 1 = Stop m = minute 1 = automatic
B = B alarm h=hour
23:2 SMART Link, ALARM LEVEL 1 TRIPPED
Chiller/heat pump has tripped, group alarm level 1.
B 0
3)
30 s 0
23:3 SMART Link, ALARM LEVEL 2 TRIPPED
Chiller/heat pump has tripped, group alarm level 2.
B 0
3)
30 s 0
23:4 SMART Link, ALARM LEVEL 3 TRIPPED
Chiller/heat pump has tripped, group alarm level 3.
B 0
3)
30 s 0
23:10 AQUA Link, I/O MODULE NO. 5 COMMUNICATION ERROR
The air handling unit’s control unit cannot establish correct
communication with I/O module no. 5, AQUA Link
B 0
3)
10 s 1
23:11 AQUA Link, PUMP MONITORING TRIPPED
Pump to AQUA Link is defective.
B 0
3)
10 s 0
Alarm group 24: SMART Link DX
24:1 SMART Link, no. 1 communication error
The air handling unit's control unit cannot establish correct
communication with the chiller/heat pump 1.
A 0
3)
30 s 1
24:2 SMART Link, no. 1 alarm tripped
Chiller 1 defective.
A 0
3)
30 s 1
24:4 SMART Link, no. 2 communication error
The air handling unit's control unit cannot establish correct
communication with the chiller/heat pump 2.
A 0
3)
30 s 1
24:5 SMART Link, no. 2 alarm tripped
Chiller 2 defective.
A 0
3)
30 s 1
24:7 SMART Link, no. 3 communication error
The air handling unit's control unit cannot establish correct
communication with the chiller/heat pump 3.
A 0
3)
30 s 1
24:8 SMART Link, no. 3 alarm tripped
Chiller 3 defective.
A 0
3)
30 s 1
24:10 SMART Link, no. 4 communication error
The air handling unit's control unit cannot establish correct
communication with the chiller/heat pump 4.
A 0
3)
30 s 1
24:11 SMART Link, no. 4 alarm tripped
Chiller 4 defective.
A 0
3)
30 s 1
Alarm group 24-25: Spare
Alarm group 26: Pre-filter
26:1 PRE-FILTER, SUPPLY AIR PRESSURE SENSOR NO. 8 COMMU-
NICATION ERROR
The air handling unit’s control unit cannot establish correct
communication with the sensor of the supply air pre-filter.
B 0
3)
10 s 1
26:2 PRE-FILTER, SUPPLY AIR FOULED
The pressure across the supply air pre-filter exceeds the
preset alarm limit for more than 10 minutes.
B 0
3)
10 m 0
26:7 PRE-FILTER, EXTRACT AIR PRESSURE SENSOR NO. 9 COM-
MUNICATION ERROR
The air handling unit's control unit cannot establish correct
communication with the sensor of the extract air pre-filter.
B 0
3)
10 s 1
26:8 PRE-FILTER, EXTRACT AIR FOULED
The pressure across the extract air pre-filter exceeds the
preset alarm limit for more than 10 minutes.
B 0
3)
10 m 0
Alarm group 27: AHU, internal filters
27:1 AHU FILTER, SUPPLY AIR PRESSURE SENSOR NO. 3/4 COM-
MUNICATION ERROR
The air handling unit's control unit cannot establish correct
communication with the sensor of the AHU supply air filter.
B 0
3)
10 s 1
