Day schedule
5.3.3.3 Day schedule
Times and days can be set when the air handling unit is to run in
the high speed mode, low speed mode or be switched off.
For each day (Monday - Sunday), six different events can
be set to occur at a given point in time. Here, it is also pos-
sible to set six different events for two exceptions under
Ex1 and Ex2. The provisions for these exceptions can then
be set under Exceptions schedule, Calendar 1 and Calen-
dar 2.
Note that the preset event will not be carried over to the
next 24-hour period. If no event is set from 00.00 hours of
the next 24-hour period, the AHU will operate in the pre-
selected operating mode preset under Schedule settings.
Settings:
Value Setting
range
Factory
settings
Day Mon/Tues/Wed/Thurs/Fri/Sat/Sun/Ex1/
Ex2
Time 00:00-23:59 00:00
Action Inactive/Total stop/Low speed/High
speed/Normal Stop/ Extended Normal
Stop/Ignore
Inactive
5.3.3.4 Exceptions schedule
Possible exceptions (Ex1 and Ex2), previously preset in the day
schedule can be set in the Exceptions schedule. Here you can
determine on which date or weekday the relevant exception shall
apply. If you select Calendar 1 or Calendar 2, which is the most
often the case, these can be set according to particulars in the
next section.
Settings:
Value Setting
range
Factory
settings
Exceptions schedule 1/2
Exceptions method Inactive/Date/Date
range/Weekday/
Calendar 1/
Calendar 2
Calendar
1/2
Date
Start date Year/Month/Day
Start weekday Each day/
Monday/Tuesday/
Wednesday/
Thursday/Friday/
Saturday/Sunday
Each day
Date range
Start date Year/Month/Day
Start weekday Each day/
Monday/Tuesday/
Wednesday/
Thursday/Friday/
Saturday/Sunday
Each day
Stop date Year/Month/Day
Stop weekday Each day/
Monday/Tuesday/
Wednesday/
Thursday/Friday/
Saturday/Sunday
Each day
Exceptions schedule
Weekday
Start date Mon 1-12/Odd/
Even/Each
Day 1-7/8-14/15-
21/22-28/29-31/
Latest 7 days/Each
day
Start weekday Each day/
Monday/Tuesday/
Wednesday/
Thursday/Friday/
saturday/Sunday
Each day
Calender 1 See next chapter
Calender 2 See next chapter
