Alarm No.
Alarm text
Function
Priority Stop Delay Resetting
0 = Blocked 0 = In operat. s = second 0 = manual
A = A alarm 1 = Stop m = minute 1 = automatic
B = B alarm h=hour
17:4 ROTARY HEAT EXCHANGER, ROTATION DETECTOR TRIPPED
No impulses from the rotation detector are registered with
the heat exchanger controller.
A
1)
1
3)4)
3 s 0
17:5 ROTARY HEAT EXCHANGER, MOTOR CONTROLLER OVER-
CURRENT
Heat exchanger motor controller has registered excessively
high current supplier to the drive motor.
A
1)
1
3)4)
3 s 0
17:6 ROTARY HEAT EXCHANGER, MOTOR CONTROLLER UNDER-
VOLTAGE
Low feed voltage is supplied to the rotary heat exchanger’s
motor controller.
A
1)
1
3)4)
3 s 0
17:7 ROTARY HEAT EXCHANGER, MOTOR CONTROLLER OVER-
VOLTAGE
High feed voltage is supplied to the rotary heat exchanger's
motor controller.
A
1)
1
3)4)
3 s 0
17:8 ROTARY HEAT EXCHANGER, MOTOR CONTROLLER EXCESS
TEMPERATURE
High temperature (90°C) inside the heat exchanger’s motor
controller.
A
1)
1
3)4)
3 s 0
17:9 ROTARY HEAT EXCHANGER, MOTOR CONTROLLER START
UP ERROR
Drive motor does not rotate during start up.
A
1)
1
3)4)
3 s 0
Alarm group 18: AYC
18:1 AYC, I/O MODULE No. 7 COMMUNICATION ERROR
The air handling unit's control unit cannot establish correct
communication with I/O module No. 7 for AYC.
A 0
3)
10 s 1
18:2 AYC HEATING, TEMPERATURE SENSOR DEFECTIVE
Heating temperature sensor is defective or is not connected.
A 0
3)
3 s 1
18:3 AYC HEATING, VALVE MONITORING TRIPPED
The heated water valve actuator is defective.
B 0
3)
10 m 0
18:4 AYC HEATING, PUMP MONITORING TRIPPED
The heated water pump is defective.
A 0
3)
20 s 0
18:5 AYC HEATING, TEMPERATURE BELOW SET POINT LIMIT
Heating water temperature is below preset set point longer
than 30 minutes.
A 0
3)
30 m 0
18:6 AYC HEATING, TEMPERATURE ABOVE SET POINT ALARM
LIMIT
5)
Heating water temperature exceeds preset set point longer
than 30 minutes.
B 0
3)
30 m 0
18:9 AYC COOLING, TEMPERATURE SENSOR DEFECTIVE
Temperature sensor for the AYC function (All Year Comfort)
cooling is defective or is not connected.
A 0
3)
3 s 1
18:10 AYC COOLING, VALVE MONITORING TRIPPED
The chilled water valve actuator is defective.
B 0
3)
10 m 0
18:11 AYC COOLING, PUMP MONITORING TRIPPED
The chilled water pump is defective.
A 0
3)
20 s 0
18:12 AYC COOLING, TEMPERATURE BELOW SET POINT ALARM
LIMIT
Heating water temperature is below preset set point longer
than 30 minutes.
A 0
3)
30 m 0
18:13 AYC COOLING, TEMPERATURE ABOVE SET POINT ALARM
LIMIT
5)
Cooling water temperature exceeds preset set point longer
than 30 minutes.
B 0
3)
30 m 0
