6.4.19 Inputs/Outputs
Can for example be used if the air handling unit will be con-
trolled/monitored via microprocessor substation or a PLC system.
External operation module 3/6 requires the TBIQ-3-2 IQlogic
+
module accessory; external communication module A/B/C
requires the TBIQ-3-1 accessory. See separate installation instruc-
tions.
Settings:
Value Setting
range
Factory
setting
External operation
module 3/6
Digital output 1/2
mode
Inactive/Air handling unit in
operation/Air handling unit in
auto operation/ Air handling
unit in manual operation/Air
handling unit in low speed
operation/Air handling unit
in high speed operation/A
alarm/B alarm/Damper
relay/Heat exchanger/Heat
exchanger defrost/Reheat/
Reheating power reduction/
Heating Boost/Morning Boost/
Intermittent night heat/Air-
fl ow down regulation/Extra
reg. sequence 1/2 heat/Extra
reg. sequence 1/2 cool/Cool-
ing/Cooling Boost/Summer
night cool/ Supply air fan in
operation/Extract air fan in
operation/Internal fi re alarm
tripped/External fi re alarm 1/
External fi re alarm 2/External
fi re alarm 1 or 2/Any fi re alarm
Inactive
Digital input 1/2 Inactive/Alarm reset/Stop AYC
heated water/Stop AYC chilled
water
Inactive
Analogue output 1 Indicates present supply
airfl ow, from 0 to air handling
unit’s max. speed (%)
Analogue output 2 Indicates present extract
airfl ow, from 0 to air handling
unit’s max. speed (%)
Analogue input
1/2*
Inactive/Set point displace-
ment/Set point displacement,
supply air/Set point displace-
ment, extract air
Inactive
External
communication
module A/B/C
External commu-
nication module
A/B/C
On/Off Off
Temperature
sensor no. 1
On/Off Off
Temperature
sensor no. 2
On/Off Off
* If analogue inputs 1 and 2 are both selected for setpoint dis-
placement, only analogue input 1 will be used.
