GB.GOLDSKE.160901
76 www.swegon.com
We reserve the right to alter specifi cations without notice.
6.4.17 All Year Comfort
The All Year Comfort function controls, via control valves, the
supply fl ow temperature to the comfort modules, cooling beams,
perimeter wall units, etc. The water temperature is measured by
two strap-on temperature sensors mounted on the water pipe of
each circuit.
All Year Comfort has functions for outdoor compensation, room
compensation, night compensation, dew point compensation as
well as the monitoring and exercising of pumps and valves.
For more information, see the All Year Comfort function guide.
Settings:
Value Setting
range
Factory
setting
Function Inactive/Cooling
water/Heating
water/
Inactive
Cooling water
and heating
water
Chilled water
Chilled water
1)
5 - 30°C 14°C
Outdoor temp compensation On/Off Off
Outdoor temp X1 -40 – +40°C 10°C
Outdoor temp X2 -40 – +40°C 20°C
Outdoor temp X3 -40 – +40°C 25°C
Outdoor temp X4 -40 – +40°C 30°C
Chilled water temp Y1 5 – 30°C 22°C
Chilled water temp Y2 5 – 30°C 18°C
Chilled water temp Y3 5 – 30°C 14°C
Chilled water temp Y4 5 – 30°C 12°C
Outdoor temp for pump start -40 - +40°C 10°C
Outdoor temp for pump stop
-40 - +40°C 7°C
Room temp compensation On/Off Off
Room temp. set point 0 - 40°C 21°C
Room temp. P-band 1 - 10 K 5 K
Room comp. night block On/Off Off
Night compensation On/Off Off
Night reduction 0 - 10 K 2 K
Time channel 1/2 start of night 00:00 - 23:59 00:00
Time channel 1/2 end of night 00:00 - 23:59 00:00
Time channel 1/2 period Inactive/
Monday/
Tuesday/
Wednesday/
Thursday/Friday/
Saturday/Sunday
Mon - Fri/Mon
- Sun/
Sat - Sun
Inactive
Dew point compensation On/Off Off
Air fl ow compensation On/Off Off
Periodic operation pump On/Off On
Periodic operation valve exercising On/Off Off
Periodic operation interval 0-168 hrs. 24 hrs.
Periodic operation period 0-60 min. 3 min.
Pump alarm Inactive/Alarm
on closed con-
tact/Alarm on
open contact/
Contactor func-
tion
Inactive
Valve alarm On/Off Off
Heated water
Heated water
1)
10 - 80°C 30°C
Outdoor temp compensation On/Off Off
Outdoor temp X1 -40 – +40°C -20°C
Outdoor temp X2 -40 – +40°C 0°C
Outdoor temp X3 -40 – +40°C 5°C
Outdoor temp X4 -40 – +40°C 15°C
Heated water temp Y1 10 – 80°C 40°C
Heated water temp Y2 10 – 80°C 30°C
Heated water temperatue Y3 10 – 80°C 20°C
Heated water temp Y4 10 – 80°C 15°C
Outdoor temp for pump start -40 - +40°C 15°C
Outdoor temp for pump stop
-40 - +40°C 18°C
Room temp compensation On/Off Off
Room temp. set point 0 - 40°C 21°C
Room temp. P-band 1 - 10 K 5 K
Room comp. night block On/Off Off
Night compensation On/Off Off
Night reduction 0 – -10 K -2 K
Time channel 1/2 start of night 00:00 - 23:59 00:00
Time channel 1/2 end of night 00:00 - 23:59 00:00
Time channel 1/2 period Inactive/
Monday/
Tuesday/
Wednesday/
Thursday/Friday/
Saturday/Sunday
Mon - Fri/Mon
- Sun/
Sat - Sun
Inactive
Air fl ow compensation On/Off Off
Periodic operation pump On/Off On
Periodic operation valve exercising On/Off Off
Periodic operation interval 0-168 hrs. 24 hrs.
Periodic operation period 0-60 min. 3 min.
Pump alarm Inactive/Alarm
on closed con-
tact/Alarm on
open contact/
Contactor func-
tion
Inactive
Valve alarm On/Off Off
All Year
Comfort
1)
Omitted if the outdoor temperature compensation
is selected.
