Symmetricom TimeSource 3100 User Guide

097-72020-01 Revision K – December 2005 TimeSource User’s Guide 137
Chapter 4 TL1 Reference
Commands
Aid Parameter Value Parameter Description
ALL MONITOR=a a = ALW Monitor is used for alarm purposes
a = INH Monitor is not used for alarm purposes
TS3100 BYPASS=a
(990-72020-04
Systems only)
a = ALW or
INH
During holdover, the traffic-bearing E1
spans on the ESCIU module pass through
the TimeSource 3100 without being
re-timed (ALW) or the E1 spans continue
to be re-timed (INH)
FREQ=a a=5 Frequency for both remote oscillator
inputs is 5 MHz
a=10 Frequency for both remote oscillator
inputs is 10 MHz
TOD=a a=CISCO Serial message sent is Cisco format
a=NTP4 Serial message sent is NTP Type 4 format
a=NONE No serial message is sent
ALMCOND=a a=ALW Alarm conditioning for outputs is enabled
a=INH Alarm conditioning for outputs is disabled
