Symmetricom TimeSource 3100 User Guide

Chapter 3 Installing the TimeSource 3100
Factory Default Values
90 TimeSource 3100 User’s Guide 097-72020-01 Revision K – December 2005
Figure 3-30. The Save Log File Dialog Box
18.Navigate to the location to where the log file is to be stored, enter a name for the
log file into the File Name field, then click Save.
19.Click Exit to complete the TimeWizard firmware installation procedure.
Factory Default Values
The parameter values initially set at the factory are shown in Table 3-9
Table 3-9. Parameter Factory Settings
<aid> Parameter Setting
TS3100 FREQ=5MHz
TOD=NONE
ALMCOND=ALW
IPNE=0.0.0.0 IPSUBNET=255.255.255.255
IPGATE=0.0.0.0
IPEM1=0.0.0.0
IPEM1PORT=0
IPEM2=0.0.0.0
IPEM2PORT=0
IPINACT=0
DCDPASSTHRU=INH DCDUSERPORT=2
BYPASS=ALW (990-72020-04 systems only)
TS3100 HOLDOVER
ALARM
TIME=24-0
SEV1=EV
SEV2=MJ
SAFF1=NSA
SAFF2=SA
