Chapter 6 Specifications
Antenna
176 TimeSource 3100 User’s Guide 097-72020-01 Revision K – December 2005
Antenna
Type: Active volute antenna, right-hand circular polarized, with
proprietary IF interface
Voltage (via signal cable): 12 V DC nominal
Current (via signal cable): 125 mA
Gain: 23 dB
Cable Type: RG-59/U (Belden 82108 or equivalent)
Cable Length: Maximum 305 m from antenna to shelf
Dimensions (excluding mount):
Height:16.5 cm
Diameter:15.0 cm
Weight:255 g
Operating Temperature: –30 °C to +80 °C
Storage Temperature: –40 °C to +80 °C
Operating Humidity: 0% to 100% relative humidity
Communication Ports
Port 1
Connector Type: 25-pin, female D connector
Connector Label: COM1
Connector Location:Connector panel
Electrical Interface: RS-232 (DTE Equivalent)
Pin that transmits data:2
Pin that receives data:3
Baud Rate: 1200 b/s, 2400 b/s, 4800 b/s 9600 b/s (factory default),
19.2 kb/s, 38.4 kb/s, 57.6 kb/s , 115 kb/s
Data Bits: 8
