Chapter 3 Installing the TimeSource 3100
Installing TimeWizard
86 TimeSource 3100 User’s Guide 097-72020-01 Revision K – December 2005
After the Download Progress dialog box closes, continue to monitor the
messages reported in the Commands area of the screen.
After the firmware file finishes downloading from the PC to the TimeSource, the
TimeSource requires more time to complete the firmware upgrade process.
During this time, it should not be interrupted. When the firmware upgrade is fully
complete, TimeWizard automatically advances to the next screen.
Verifying the Firmware Version
12.After the firmware has downloaded successfully, the Status Information screen
appears, as shown in Figure 3-26.
Figure 3-26. The Status Information Screen
Verify that the GPS.hex Ver and TS3000.hex Ver fields indicate that the correct
versions of the GPS.hex and TS3000.hex firmware are now installed.
Setting Alarm Parameters
13.Click Next>> when the correct versions are installed. The Set the Alarm
Parameters screen appears, as shown in Figure 3-27.
Note: After the TS3000.hex download operation successfully
completes, the TimeSource reboots so that it can use the newly
installed firmware. Upon rebooting, the system’s output might enter
the degraded region of the PRS mask for up to one hour.
