Chapter 6 Specifications

Time of Day Outputs

180 TimeSource 3100 User’s Guide 097-72020-01 Revision K – December 2005

Cisco Systems Format

Connector Type: RJ-45

Connector Label: TOD

Connector Location: Connector panel

Electrical Interface: RS-485

Baud Rate: 9600 b/s

Bit Configuration: 8 data bits, No parity, 1 stop bit

Data Format: See Figure 6-2

Figure 6-2. NTP Type 4 Data Format
