097-72020-01 Revision K – December 2005 TimeSource 3100 User’s Guide 47
Chapter 3 Installing the TimeSource 3100
Installing the Antenna
Installing the Antenna
These installation procedures are to be used in support of local company
procedures and the Installation Job Specification.
Prior to installing the antenna, the site, antenna location, lightning suppressor
location, cable route, and all other details should be planned as described in
Antenna Location Guidelines, on page 33.
To install the antenna, refer to Figure 3-1, and perform the procedure that follows.
Figure 3-1. Antenna-to-Shelf Cabling
Warning: To prevent possible lightning-induced damage, install the
lightning suppressor away from electrical devices or cabling that may
induce arcing.
To Next Page
