Chapter 4 TL1 Reference
Parameters
96 TimeSource User’s Guide 097-72020-01 Revision K – December 2005
Figure 4-3. Deny Response Format
Parameters
The parameters that may be used in commands, responses, and messages are
defined in Table 4-1. When a parameter uses the same values in every instance,
those values are listed with the parameter in the table. When the context requires
different values for a parameter, the value is listed with the parameter in the
applicable commands, responses, and messages.
Table 4-1. Parameter Definitions
Parameter Definition
<aid> Access identifier for the object of the command or message. It may have
more than one part.
<almcde> Alarm code. Identifies the severity of the alarm based on its priority of action.
If multiple alarms are reported, almcde is the highest severity of those
reported.
<alt> Antenna location altitude in meters, specified to the thousandth of a meter,
referenced to mean sea level, in the format mm.mmm.
<atag> Automatic message tag. It is incremented by one for each autonomous
message. The <atag> value is a whole number from 001 through 999, which
is reset to 001 at reset or when it rolls over.
<command> Echo of the entered command.
<conddescr> Text description of the condition. The <conddescr> value is limited to 64
characters starting and ending with a backslash and a double quotation mark
(\"). Refer to the Troubleshooting chapter of this manual for the list of values.
<condeff> Effect on the condition of the equipment.
<condtype> Type of alarm condition.
<ctag> Correlation tag used to correlate input and response messages. The ctag
contains 1 to 6 characters. It must be included in a command, and the same
ctag is returned in the response.
^^^<sid>^<date>^<time>
M^^<ctag>^DENY
^^<errcode>
^^^/* <error message> */
^^^/*LINK:,link>,CMD:<command>*/
;
