097-72020-01 Revision K – December 2005 TimeSource User’s Guide 149
Chapter 4 TL1 Reference
Commands
MTIE Response Format:
<sid> <date> <time>
M <ctag>COMPLD
"SPAN-a:MTIE-a,<monval>,<vldty>
,,,,<mondat>,<montm>"
...
...
...
"SPAN-a:MTIE-a,<monval>,<vldty>
,,,,<mondat>,<montm>"
/*LINK:<link>,CMD:<command>*/
;
MTIE Data types:
One 15 minute bin from the last 24 hours of data. To select a 15 minute bin, enter
mondat and montm. Any mondat/montm combination outside of the past 24 hour
window is denied. Any time increment may be entered. The system rounds the
value to the nearest bin. Entered minutes of 1 to 15 correspond to the first 15
minute bin, 16 to 30 correspond to the second 15 minute bin, etc.
One day summary from the last 7 days of daily summaries. To select one daily
summary, enter mondat, but do not enter montm. Any mondat not in the previous
7 day window is denied.
Parameter Value Description
SPAN-a a = A E1 span A input
a = B E1 span B input
MTIE-a a = 1S, 2S, 4S, 10S,
40S, 100S, 300S,
900S, 1800S, 3600S,
7200S, 14400S,
28800S, or 86400S
MTIE monitored type, where a is time
intervals in seconds
<monval> One 15 min. bin from
the last 24h of data
Monitored value
<vldty> COMPL Data is valid
NA Data is not valid
MONDAT=a-b a = 1 to 12 Monitor date, month of the year
b = 1 to 31 Monitor date, day of the month
MONTM=a-b a = 0 to 23 Monitor time, hour of the day
b = 0 to 59 Monitor time, minute of the hour
