097-72020-01 Revision K – December 2005 TimeSource User’s Guide 155
Chapter 4 TL1 Reference
Commands
/* LINK: 5001, CMD: RTRV-PM-EQPT::SPAN-A:C:: PHASE1S,,,,, */
;
PHASE1M Response Format:
<sid> <date> <time>
M <ctag>COMPLD
"SPAN-a:PHASE1M,<monval>,<monval>,
<monval>,<monval>,<monval>,<monval>,
...
...
...
<monval>,<monval>,<monval>,<monval>,
<vldty>,,,,<mondat>,<montm>"
/*LINK:<link>,CMD:<command>*/
;
PHASE1M Data types:
The TimeSource 3100 collects a full 7 days of 1 minute phase data.
The 1 minute phase data is displayed in 1 hour groups. Each request for 1
minute phase is synchronized to the hour.
Any mondat/montm combination outside of the past 7 day window is denied. Any
time increment may be entered. The system rounds the value to the nearest
hour, i.e., the minute and second field of the montm is ignored.
The first value (monval) is the oldest value in the range selected. For example, if
montm = 8:45:32, the first monval will exceed time 8:00:00 followed by the value
at 8:01:00, etc.
Parameter Value Item Addressed
SPAN-a a = A E1 span A input
a = B E1 span B input
PHASE1M — Phase 1M monitored type, which shows 1
min. phase data in 1 h groups of data
<monval> Oldest value in the
range selected
from the <montm>
value assigned in
the command
Absolute monitored phase value
<vldty> COMPL Data is valid
NA Data is not valid
