TB30s SIP Administrator Guide v1.3 Page 96 of 259
SIP4">sip:1414@as.iop1.broadworks.net;user=phone</identity></remote>
</dialog></dialog-info>
LED steady lit - if no Proceeding (direction=recipient) tags are present,
and any of the state tags for that resource uri is Proceeding with
direction = originator or any of the state tags is Confirmed
<?xml version="1.0" encoding="UTF-8"?><dialog-info
xmlns="urn:ietf:params:xml:ns:dialog-info" version="11" state="full"
entity="thomson4@as.iop1.broadworks.net"><dialog id="bG9jYWxIb3N0NDU5NDY4OjA="
direction="initiator"><state>confirmed</state>
<local><identity display="BroadSoft
SIP4">sip:thomson4@as.iop1.broadworks.net</identity><identity display="BroadSoft
SIP4">tel:+12408881414;ext=1414</identity></local>
<remote><identity display="Broadsoft
SIP1">sip:1411@as.iop1.broadworks.net;user=phone</identity></remote>
</dialog></dialog-info>
LED off - if all the state tags are Terminated
<?xml version="1.0" encoding="UTF-8"?><dialog-info
xmlns="urn:ietf:params:xml:ns:dialog-info" version="7" state="full"
entity="thomson2@as.iop1.broadworks.net"><dialog id="bG9jYWxIb3N0NDU5NDY5OjA="
direction="recipient"><state>terminated</state>
<local><identity display="Broadsoft
SIP2">sip:thomson2@as.iop1.broadworks.net</identity><identity display="Broadsoft
SIP2">tel:+12408881412;ext=1412</identity></local>
</dialog></dialog-info>
User action
There are three different statuses defined when the BLF Key is pressed:
1. LED in idle - it causes speed dial provisioned number
2. LED steady on – it causes speed dial provisioned number
3. LED blinking –it causes launch call pickup (See below 3.3)
Call pickup (directed pickup)
The method to launch pickup will depend on the local/sc configuration flag.
The number used to launch pickup when BLF key is pressed in led blinking
state will be taken from the dialog-info section of the received NOTIFY.
The starcode used for pickup will be in accordance with your server
configuration.
Feature Activation
A) Through WebGui:
To Next Page
