TB30s SIP Administrator Guide v1.3 Page 229 of 259
3. TB30 Phone Specifications
3.1 Presentation
The TB30 will be able to send the queries to the HTTP server, and display the XML pages sent
back from the server, and enable the user to navigate in simple menus, in order to select an entry,
view the number, and call the contact.
3.2 Configuration
The URL of the query CGI that has to called in order to perform a search in the phonebooks
must be specified in the configuration file of the TB30. They are written in the following way:
http://www.server.com/services/phonebookl/search.php?IP_ADDR=#IP&MAC_ADDR=#MAC&NAME=#SEARCH
In those URL if some pattern starting with the “#” character are found and they
match some predefined strings, they are replaced by the corresponding values.
Here are the conversions:
#IP  replaced by the IP address in decimal. Ex: 192.68.0.1
#MAC  replaced by the MAC address in hexa. Ex: 000E504EA77B
#SEARCH  replaced by the entry of the search request. EX: dup
An example of config file:
[TB30s_common.txt]
…
Phonebook1_url =
http://www.server.com/services/phonebookl/search.php?IP_ADDR=#IP
&NAME=#SEARCH
Phonebook1_name = Thomson Telecom
Phonebook2_url =
http://www.server1.com/pb/search.php?NAME=#SEARCH
Phonebook2_name = Inventel
Phonebook3_url =
http://www.server2.com/services/phonel/s.php?MAC_ADDR#MAC&Na
me=#SEARCH
Phonebook3_name = Yellow pages
…
3.3 Cancel Key
At anytime, if the Cancel hard key is pressed, the phone returns to its IDLE mode.
