TB30s SIP Administrator Guide v1.3
Page 228 of 259
<ThomsonPhoneMenu>
<MenuItem>
<Name>Arrh
Foulard</Name>
<URL>
http://www
.server.co
m/get32results_1.php
</URL>
</MenuItem>
….
<MenuItem>
<Name>Roger
Ziad </Name>
<URL>
http://www
.server.co
m/get32results_7.php
</URL>
</MenuItem>
</ ThomsonPhoneMenu>
Each
URL
in
the
menu
will
send
back
a
T
homsonPhoneBook
XML
p
age
as
des
cribed
in
the
previous section.
234
236
Table of Contents
Default Chapter
3
Table of Contents
3
Part 1 Safety Information
8
Operating Conditions
8
Location Safety Instructions
8
Care
8
Connections
8
Qualified Service
9
Part 2 Product Overview and Connections
10
Introduction
10
Note and Caution
10
Package Contents
10
Connecting to the Network and the Pc
11
Ip Phone Cable Connections
11
Powering up the Phone
12
Connected a Headset
13
Connection
13
Headset Compability
13
Aux Wireless Headset Setup
13
Using Headset
13
Figure 2 Headset Connection
13
Table 1 Handset/Headset Pin
13
Overview
14
Main Features
14
Supported Features
14
Supported Protocols
15
Abbreviations
17
Part 3 Phone Operations
18
General Appearance
18
Tb30 General Appearance
18
Physical Features
19
Tb30 User Panel
19
T Able 2 Tb30 P Hyscical F Eatures
21
Display
22
Definitions of Soft Keys
22
Icons & Indicators
24
Definitions of Led
25
Extension Module
25
Memory
25
Led Indicator
25
Power Supply
25
Tb30 Physcical Features Table 3 Definitions of Soft Keys Table 4 Definitions of Led
25
Part 4 Call Services
26
Talking Mode & Operations
26
Kinds of Communication Mode
26
Operation of off Hook
26
Operation of on Hook
26
Operation of Mode Switch During Call
26
Table 5 Operations Mode Switch During Call
26
Main Call Functions
27
Make a Call
27
Last Number Redial
28
Speed Dial
28
Answer a Call
29
Reject a Call
29
Call Back
29
Call Forward
30
Transfer Message to Voice Mail
30
Call Functions During Conversation
31
Hold and Retrieve a Call
31
Call Transfer
31
Date Time
31
Conference Call
32
Options During a Call
33
Volume Adjustment
33
Mute
33
Multi Line
34
Display of Line/Call Status
34
Pick up
35
Park up
36
Phone Book & Call Log
36
Call Logs
36
Missed Calls
37
Phone Book
38
Character Input- Edit Mode
39
Table 6 Character Input Method Table
39
Part 5 Configuration through Lcd
40
Menu List
40
Figure 5 Operationsmenu LCD Display
41
Operation Menu Display
42
Home Operation Menu Display
42
Config Menu Display
42
Admin Menu Display
43
Option Menu Display
44
Detailed LCD Menu Settings
45
Alarm Clock
47
Ntp Setting
52
Part 6 Configuration Via Web Interface
54
Configuration through the Web Interface
54
Find Ip Address
54
Detailed Web Pages
55
User Mode Web Pages
56
Admin Mode Web Pages
58
Part 7 Auto-Provisioning
61
Automatic Phone Provisioning with Tftp
61
Automatic Phone Provisioning with Http
65
Usb Automatic Phone Provisioning
67
Part 8 Ringtones Configuration
69
Figure 6 Ringtone Converter
69
Figure 7 Ringtone Converter
70
Figure 8 Ringtone Composer
70
Figure 9 Ringtone Composer
71
Part 9 Backlight Saving Mode
73
Part 10 Feature Overview
74
Unauthenticated Srtp Need to be Configured (3440) - V1.72
74
Introduction
74
Voice Mail Key Is Active All the Time (3600) - V1.72
75
Introduction
75
Requirement
75
Voice Mail Key Dial "Voice Mail Telephone Number" Even no Subscribe (4066)
76
Introduction
76
Requirement
76
Display Customer Icon in Standby (3959) - V1.72
77
Introduction
77
Requirement
77
Standby
77
Reset to Default Single Parameter (3864) - V1.72
79
Introduction
79
Phone Lock (3999) - V1.72
80
Introduction
80
Requirement
80
Phone Lock Mode = 0
80
Phonelockmode=1
80
Example Setting
82
Password Protection
82
Block Web Gui (4067) - V1.72
86
Introduction
86
Requirement
86
Display Customer Icon on Web (4096) - V1.72
87
Introduction Requirement Usb Login/Logout (3995) V1.72
88
Introduction
88
Requirement
88
Call Log Prefix
89
Venezuela Numbering Plan
90
Lldp
92
Cirpack Mgc & Hua Wei Softswitch
93
Hua Wei Softswitch (Mgc_Service = 1)
93
Cirpack MGC Service (Mgc_Service = 2)
96
Blf
98
User-Oriented BLF
98
High Level Technical Description
98
User Interaction
99
Examples with Asterisk Sip Server as Notifier
100
List-Oriented BLF
102
LED State
102
User Action
103
Call Pickup (Directed Pickup)
103
Feature Activation
103
Presence Basesd Blf
105
Feature Activation
106
Acr Response
107
Attend Transfer
108
Preferred Identity
109
Dscp of Dhcp
110
Input Mode
111
Config Without Reload
112
Ccbs Enable/Disable
113
Security Features
114
Improve Https Aps Feature
117
Support Encryption of Configuration Files in Aps
119
Call Dialing from Webgui
122
Sip Message During Call (Rfc 3428)
126
Dns Query ( Circular Method)
128
Support Remote Call Logs for Local User
130
Transfer on Ringing
133
Call-Hold "Inactive" Method
135
Call-Hold “Inactive” Method
137
Comverse: Line and Service Supervision (Reg & Ua-Profile Event Package)
137
Comverse: Redirecting Identity and Name Presentation
147
Multi-Registration on a same Server
149
Support Private Number
150
Softkey Left Scrolling in Talking Mode
151
Incoming Call During Transfer
152
Number Display in Standby
158
Improved Shared Call Appearance (Sca)
159
Second Dial-Tone for Pbx-Like Environments
161
New Specific Keys in the Dial Plan
163
New Error Message Display for 403 Response
165
Services Supervision Feature
166
Star Codes
170
Call Pick-Up Service
171
Behavior
171
Call Forward Service
172
Behavior
173
Do Not Disturb Service
174
Behavior
175
Transfer to Voicemail Service
175
Behavior
176
Call Park Service
176
Call Blocking Service
177
Behavior
177
Privacy Call Service
178
Behavior
178
Call Waiting Service
178
Behavior
179
Special Services Activation through Dtmf
179
Behavior
180
Other Special Services Activation
180
Behavior
181
Ad-Hoc Conf (Rfc 4579)
182
Sylantro Sip-B
185
Identity Header Precedence
186
Nat Keep Alive
188
Trusted Ip for Notify "Check-Sync
190
Reboot on Notify "Check-Sync; Reboot=True
192
Reboot on Notify “Check-Sync; Reboot=True”
193
Trusted Ip for Notify “Check-Sync”
193
Downloadable/Uploadable Local Phonebook
193
Mixed Paging Remote Phonebook
195
Login/Logout - Disable Subscribe to Dialog
197
Tracing Tool
199
Download and Update Tone and Language Tables
202
How to Modify the Templates
204
Sip Message Support (Rfc 3428) for Status Display Applications
208
Disable Call Waiting Tone
209
Soft Keys Reordering
210
Early Media Type Parameter
211
Login/Logout
212
Broadsoft Shared Call Appearance
213
Automatic Hang up
214
Call Park Type
215
Ringer in the Headset
216
Ringer off
216
Ignoring Firmware Update
216
Call-Info Header with Answer-After Parameter
217
Network Conference
218
Configurable Refer-To Header Population
219
Check Phonebook Domain Name
220
Aps Improvement
220
Talk and Hold Event Packages for Click-To-Answer and Other 3Pcc Scenarios
221
Persistent Vlan
221
User Class Identifier
222
Additional Softkey Control
223
Call Progress Indication Control
224
Phone Number Display in Idle Mode Control
225
Automatic Call When Offhook
226
Hide Missed Calls Flag
227
Autoanswer Device Routing
227
Keyword Definition and Usage
227
Daylight Saving Refinements
228
Ntp Address Source Configuration
229
Information Shortcut-"Menu" Long Press
229
Information Shortcut-“Menu” Long Press
230
Tb30 Sip Distinctive Ringing and Cwt Using <Alert-Info> Header
230
<Alert-Info> Header and Ringing Management
230
System Ringers
230
Void or Not Understood Alert-Info
230
Alert-Info with Local URL
230
Alert-Info with URN
230
Alert-Info with Info Parameter
231
<Alert-Info> Header and Call Waiting Tones Management
231
Description
231
System Melodies and Call Waiting Tones Download
231
Part 11 - Remote Phonebook Specification
232
Description of the Service
232
Server Specifications
232
2.1 General Structure
232
2.2 Phone Query
233
2.3 XML Tags Used by TB30
233
2.4 Answer to the Request from the Server
234
2.4.1 no Answers
234
2.4.2 Less than 32 Results to the Query
234
2.4.3 more than 32 Results to the Query
234
Tb30 Phone Specifications
236
3.1 Presentation
236
3.2 Configuration
236
3.3 Cancel Key
236
3.4 Accessing the Phonebooks
237
3.4.1 Mgcp
237
3.4.2 Sip
237
3.5 Query Menu
237
3.6 Incoming Call During Search
238
3.7 Displaying Empty Phonebook
238
3.8 Displaying Less than 32 Results Phonebook
238
3.9 Displaying more than 32 Results Phonebook
238
3.10 Displaying an Entry in the Phonebook
239
3.11 Calling an Entry in the Phonebook
239
3.12Timeout
239
Introduction
240
Enable Telnet Service
240
Part 12 Telnet Activation
240
Open a Telnet Session
241
Telnet Commands
242
Reset to Default
243
Part 13 Tr069 & Tr111
244
Purpose
244
Introduction
244
Cpe Configure Settings
245
Webpage
245
Parameter in Config File & CLI
246
Supported Tr069 Rpc Methods with Tb30
247
List of Supported Rpc in Tb30
247
Acs Http Connection Flow
247
Supported Rpc Introduction
248
Getrpcmethods
248
Getparameternames
248
Getparametervalues
248
Setparametervalues
248
Getparameterattributes
249
Setparameterattributes
249
Reboot
249
Upload
249
Download
249
Factoryreset
249
Detail Descrition of Download
249
Download Supported File
249
TR-111 Support with TB30
251
About Tr-111
251
TR-111 Part I: Device Gateway Association
251
TR-111 Part II: Connection Request Via NAT Gateway
251
Rpc Trigger
252
Acs Initial the Connect
252
Cpe Initial the Connect
252
Example
252
Part 14 Troubleshooting
254
Part 15 Appendix
255
Configuration and Commands
255
Examples of Files to Configure Auto Provisioning Via Tftp
257
Release Package Firmware
266
Able 7 Dsp and Boot Code Used
266
5
Based on 1 rating
Ask a question
Give review
Questions and Answers:
Need help?
Do you have a question about the Technicolor TB30 and is the answer not in the manual?
Ask a question
Technicolor TB30 Specifications
General
Brand
Technicolor
Model
TB30
Category
IP Phone
Language
English
To Next PageTo Next PageTo Previous PageTo Previous Page
Loading...
Need help?
General
