TB30s SIP Administrator Guide v1.3 Page 142 of 259
Multi-registration on a same server
TB30 is able to support multi-registration on the same server. The main line
is the master.
“Registered” status icon will be driven by the main line registration status.
Function key 1 will always be assigned to the main line. Multi registration
can include Main line.
The phone behaviour will be the same for the main line and other registered
lines for all features including register.
The phone supports multi-registration so that each line will register with
server with different credential and extension number.
This document addresses the improvements to be done in TB30 to enhance
its support for this feature.
Feature Activation
A new parameter is needed to configure this function and with some
additional definitions listed below.
Via the web GUI:
An additional item will be created in the roll down “Type” menu: Multi-
registration. This roll down type will always be shown.
The function key assigned to multi-registration will have the following
parameters separated by “|” (vertical bar):
- Line number
- Authentication username
- SIP password
- Phone Name (Optional)
Via APS:
APS in [sys] section of both Common or Specific-MAC config files with the
new Parameter:
M will be used to denote the option for multi-registration, like below:
[sys]
…..
Current_Max_Multiline=5 (available overall number of Mulit-registration line is Multiline-1)
FeatureKeyExt02=M/:<sip:2001|username|password|PhoneName2001>
FeatureKeyExt03=M/:<sip:2002|username|password|PhoneName2002>
FeatureKeyExt04=M/:<sip:2003|username|password|PhoneName2003>
….
Via Telnet
To configure, open a command line console, and telnet the phone.
