TB30s SIP Administrator Guide v1.3 Page 58 of 259
Automatic phone provisioning with HTTP
Also the provisioning can be carried out via HTTP. For that, it is necessary to follow following
steps
Needed :
1 router DHCP
1 TB30 (SIP or MGCP)
The last version of the firmware
Process of auto provisioning in the theory:
At the time of the connection of a phone to the network, it will ask an IP address to DHCP
server. This one will provide him an IP address. While going on the WEB interface of the phone
in mode admin, you can upgrade the firmware.
Process of auto provisioning in the practice:
1. Do not connect the phone with electricity. Connect an end of the cable (RJ45) in the
Ethernet LAN port at the back of the phone and the other end is plugged into the
router DHCP.
2. Restore the default parameters. With this intention, it is necessary to maintain inserted
the keys "headset" (ear-phone) and "transfers" (dumb) of the phone
3. Connect phone with electricity.
Maintain the keys "headset" (ear-phone) and "transfers" (dumb) of the phone inserted,
until seeing that the provisioning is carried out.
4. The phone not having for the moment anything with provision and no gateway to
connect itself, it will continue to blink.
5. Find the phone IP address (provided by router DHCP). So :
If MGCP phone :
Press on the key menu of the phone
Press on the softkey admin
Press on the button OK of the phone
Select Network configuration while going down with the arrows
Select IP address and note the address indicated
If SIP phone:
Press on the key menu of the phone
descend the cursor using the low button until Information
Select Information and note the IP address indicated
6. Open a WEB browser (Internet Explorer, Mozilla,…)
