TB30s SIP Administrator Guide v1.3 Page 139 of 259
FeatureKeyOpt04=dialog(1)regDND(1)ua-profile(0:cfu(0)dnd(0)sf(0)hg(0))
FeatureKeyOpt05=dialog(0)regDND(0)ua-profile(1:cfu(1)dnd(1)sf(0)hg(0))
FeatureKeyOpt09=dialog(0)regDND(0)ua-profile(1:cfu(0)dnd(0)sf(1)hg(0))
FeatureKeyOpt10=dialog(0)regDND(0)ua-profile(1:cfu(0)dnd(0)sf(0)hg(1))
…
ServiceSupervisionStart=7
ServiceSupervisionOrder=CallFwd(1)DND(2)SecFilter(0)HuntGroup(0)
….
[sip]
….
CallFwdFlg=sc // StartCode for call forward (self phone)
CallFwdOffSC=*211*
CallFwdAlwaysSC=*21x*
DNDFlg=sc // StartCode for DND (self phone)
DNDOnSC=*31#
DNDOffSC=*32#
SFOnSV=*270x* // StartCode for SF (supervised phone)
SFOffSV=*271*
HGOnSV=*71x# // StartCode for HG (supervised phone)
HGOffSV=*70x#
…
Remark:
- The default sequence of ua-profile can be changed, like
dnd(0)cfu(0)hg(0)sf(0)
- ua-profile value should be set to 1 in order to activate the services
supervision.
- 0 for disable, default value; 1 for enable; any other value(except 0 or 1)
or empty is considered as disable
- if duplicated, cfu(0)cfu(1)dns(0)sf(0)hg(0), the first one is valid.
Via Telnet:
Below shows some significant telnet commands for this case. For more
information, please refer to TB30S_Config File Syntax_V0034.pdf.
1. Set the function key to be Supervised line with phone number
2. Enable the line supervision and service supervision
4. Enter the starcodes flag with starcode
[administrator]# sys set fk 3 S/<sip :2003>
[OK] Set OK
[administrator]# sys show fk_blf_opt 3
Feature Key BLF Option[ 3] :dialog=Enable ; regDND= Disable ;ua-profile= Disable
[administrator]# sys show fk_blf_opt 3 1 0 0
[administrator]# sip set DNDFlg sc
[OK] Set OK
[administrator]# sip set DNDOnSC *31#
[OK] Set OK
[administraotr]# sip set DNDOffSC *32#
[OK] Set OK
