TB30s SIP Administrator Guide v1.3 Page 138 of 259
A new page is added called Service code in Advanced -> Service code. All
the Starcode, which are used for monitoring to the supervised phones will be
put there and be denoted by SV.
Enter the starcodes for SFOnSV , SFOffSV, HGOnSV and HGOffSV
respectively and Apply.
Via APS:
In order not to conflict with the original user-oriented BLF, a new parameter
will be added in Common and MAC configuration files to enable the feature
of line supervision of registration and service supervision for each function
key.
The existing parameters for user-oriented BLF will be used:
Current_Max_Multiline=10 (default)
FeatureKeyExtXX =S/<sip:xxxx>
New parameter:
FeatureKeyOptXX=Dialog(1)regDND(0)ua-
profile(0:cfu(0)dnd(0)sf(0)hg(0)),
Where,
0 is disable, 1 is enable
XX is the number function keys used with supported extension modules,
from Ext 01~ 66.
Dialog – current BLF (Dialog only)
regDND - registration status with DND
cfu - Un-conditional call forward
dnd – Do Not Disturb
sf - Secretary filter
hg – Hunted group
Default setting:
FeatureKeyOptXX=dialog(1)regDND(0)ua-
profile(0:cfu(0)dnd(0)sf(0)hg(0))
[sys]
…
Current_Max_Multiline=2
FeatureKeyExt03 =S/<sip:2003>
FeatureKeyExt04 =S/<sip:2004>
FeatureKeyExt05 =S/<sip:2005>
FeatureKeyExt09 =S/<sip:2007>
FeatureKeyExt10 =S/<sip:2022>
FeatureKeyOpt03=dialog(1)regDND(1)ua-profile(0:cfu(0)dnd(0)sf(0)hg(0))
