TB30s SIP Administrator Guide v1.3 Page 162 of 259
B) Through APS:
For this purpose, two new parameters have been included in the [sys]
section of the Common/MAC config files, to be able to activate the feature.
[sys]
...
ServiceSupervisionFK=0
ServiceSupOrder=callfwd(0)dnd(0)secFilter(0)huntgroup(0)
...
The parameter “ServiceSupervisionFK” could be a value from Multiline+1
(default) to max number of function keys available (10, 38 or 66 if using
extension modules).
The parameter “ServiceSupOrder=callfwd(a)dnd(b)secFilter(c)huntgroup(d)”
could have the following values, where a, b, c, d values can be 0, 1, 2, 3 or
4:
 0 means the function is not supervised.
 the other values are the order of the function key affected to this
service.
CallFwd is linked to “cfu_on” valiable
DND is linked to “dnd” valiable
SecFilter is linked to “sf_on” valiable
HuntGroup is linked to “hg_rdy” valiable
For example:
[sys]
Current_Max_Multiline=5
ServiceSupervisionFK=7
ServiceSupOrder=callfwd(2)dnd(1)secFilter(0)huntgroup(0)
Here,
- Call Forward service will be supervised on function key 8.
- Do Not Disturb service will be supervised on function key 7.
- Secretarial Filtering will not be supervised at all.
- Hunting Group will not be supervised at all.
So, function keys 6, 9 and 10 could be assigned to anything else.
C) Through Telnet:
For this purpose, two new parameters have been created, described as
follow:
sys set ServiceSupervisionStart [id]
sys set ServiceSupervisionOrder <CallFwd> <DND> <SecFilter> <HuntGroup>
(Value: 0~4,)
To configure, open a command line console, and telnet the phone:
