TB30s SIP Administrator Guide v1.3 Page 193 of 259
Feature Activation
To use Tracing tool, a telnet connection has to be open. Then, feature will be
enabled or disabled through a command: sip tracer on / sip tracer off.
Usual steps and output example:
telnet <ip>
Login: administrator
Password: 789234
[administrator]# sip tracer on
[administrator]#
[administrator]# Recv from udp: 10.0.0.5:5060 00:00:00:01:066 (937 bytes)
INVITE sip:2205@10.0.0.55:5060 SIP/2.0
Via: SIP/2.0/UDP 10.0.0.5:5060;branch=z9hG4bK2b55f27f;rport
From: "Thomson-2204" <sip:2204@10.0.0.5>;tag=as1b93c676
To: <sip:2205@10.0.0.55:5060>
Contact: <sip:2204@10.0.0.5>
Call-ID: 7b068be424cee3565279b5cb075e248b@10.0.0.5
CSeq: 102 INVITE
User-Agent: Asterisk 1.4.11
Max-Forwards: 70
Remote-Party-ID: "Thomson-2204" <sip:2204@10.0.0.5>;privacy=off;screen=no
Date: Mon, 14 Jan 2008 14:17:14 GMT
Allow: INVITE, ACK, CANCEL, OPTIONS, BYE, REFER, SUBSCRIBE, NOTIFY
Supported: replaces
Alert-Info: <http://notused.com>;info=Clocks
P-Asserted-Identity: <sip:Asterisk@10.0.0.5>
Content-Type: application/sdp
Content-Length: 254
v=0
o=root 2036 2036 IN IP4 10.0.0.5
s=session
c=IN IP4 10.0.0.5
t=0 0
m=audio 17836 RTP/AVP 0 8 101
a=rtpmap:0 PCMU/8000
a=rtpmap:8 PCMA/8000
a=rtpmap:101 telephone-event/8000
a=fmtp:101 0-16
a=silenceSupp:off - - - -
a=ptime:20
a=sendrecv
Sent to udp: 10.0.0.5:5060 00:00:00:01:096 (259 bytes) SIP/2.0 100 Trying
Via: SIP/2.0/UDP 10.0.0.5:5060;branch=z9hG4bK2b55f27f;rport
From: "Thomson-2204"<sip:2204@10.0.0.5>;tag=as1b93c676
To: <sip:2205@10.0.0.55:5060>
Call-ID: 7b068be424cee3565279b5cb075e248b@10.0.0.5
CSeq: 102 INVITE
Content-Length: 0
Sent to udp: 10.0.0.5:5060 00:00:00:01:126 (472 bytes) SIP/2.0 180 Ringing
