TB30s SIP Administrator Guide v1.3 Page 198 of 259
Words the admin can modify are the ones between xml tags.
Limitations:
1. Tone table limits - >
 Country-TableName is up to 64 characters,
 Num-of-Element is up to 6,
 Num-of-Tones is up to 4,
 Freq (frequency) is up to 3000Hz,
 Amp is between -800 ~ +30 (*0.1 db),
 Duration is up to 60000 seconds.
2. Language table limits - >
Length limit - > refer to the limit of MMI display
 LCD Central Line – 20 characters (TB30),
 right upper corner of LCD – 6 characters;
 soft keys – 6 characters (TB30),
Reserved characters should be used as follows within Language and Tone
tables:
& → &
< → &lt;
> → &gt;
‟ → &apos;
” → &quot;
How to upload the Templates:
Language and tone tables can be uploaded using APS, through telnet
application or via Web GUI.
A) Through the Web Gui:
Utility ->Lang Table Update or Tone Table Update
