Analyzing waveforms Set up MIL-1553 search parameters

Click the Search For selections Frame (see page 347), Identiﬁer (see page 347), Data (see page 348),

End of Frame

(see page 348), Missing ack (see page 348),orBit Stuff Error (see page 349) ,toview

their parame t

ers.

What do you want to do next?

Learn about bus setups. (see page 95)

Search for d

ata

The data type options available in Search For Data are Data, and Parity.

Search for RT/IMG Time

The data type options available in Search For RT/IMG Time are Search when data is, Maximum

Time and Minimum Time.

DSA/DPO70000D, MSO/DPO/DSA70000C, DPO7000C, and MSO/DPO5000 Series 359
